纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-083[01]) - HARNESS ASSY, UPPER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
947 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN13E01606P1 | [1] | WIRE HARNESS | SM |
| 2. | YN13E01462P1 | [1] | CABLE,2670mm L | KOB2670mm Long (105-7/64 in) |
| 3. | YN13E01463P1 | [1] | CABLE,1660mm L | KOB1660mm Long (65-21/64 in) |
| 4. | YN13E01441P2 | [1] | CABLE,300mm L | KOB300mm Long (11-13/16 in) |
| 5. | YN13E01436P1 | [1] | CABLE | KOB540mm Long (21-1/4 in) |
| 13. | PY01P01043D8 | [8] | CABLE TIE,102mm L | KOBWire Ties -- 368mm Long |
| 25. | ZM73C08020 | [2] | BOLT,M8x20mm - Course Thread | KOBM08x1.25x20mm (Incls. Washer) |
| 27. | ZW16X08000 | [2] | WASHER | KOBID 08 x OD 17 x Th 1.6mm |
| 28. | ZM73C10020 | [1] | BOLT,M10x20mm - Course Thread | KOBM10x1.50x20mm (Incls. Washer) |
| 29. | ZW16P10000 | [1] | WASHER | KOBID 10.5 x OD 21 x Th 2.0mm |
| 30. | ZN18C08007 | [2] | NUT | KOBM08x1.25mm |
| . . | YN13E01495P1 | [1] | CABLE | SMHarness, Not Shown (Adjustable Relief) |
