纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-084[00]) - HARNESS ASSY, UPPER (PATTERN CHANGER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
805 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN13E01438P1 | [1] | WIRE HARNESS | KOB |
| 2. | YN13E01375P1 | [8] | CLIP,M8 x 8.20mm Shank | KOBAnchor Wire Ties |
| 3. | PY01P01043D3 | [8] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 4. | EW02E01015D6 | [1] | CLIP | KOBClamp -- Ø15x22mm Long |
| 5. | ZM73C08020 | [1] | BOLT,M8x20mm - Course Thread | KOBM08x1.25x20mm (Incls. Washer) |
