纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-085[01]) - HARNESS ASSY, FLASHER AND ALARM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
583 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM80S00001F1 | [1] | LAMP | KOBFlashing -- See Fig 01-085 [02] |
| 2. | YM80S00001F2 | [1] | LAMP | KOBFlashing -- See Fig 01-085 [02] |
| 3. | 2420R372D19 | [1] | GROMMET | KOB |
| 4. | 2420Z1322 | [1] | GROMMET | KOB |
| 5. | PY01P01043D3 | [13] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 6. | YN13E01375P1 | [9] | CLIP,M8 x 8.20mm Shank | KOBAnchor Wire Ties |
| 7. | YN13E01630P1 | [1] | HARNESS | KOB |
| 8. | YN53S00003F1 | [1] | ALARM | KOB |
| 9. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 10. | ZW16P08000 | [2] | WASHER | KOBID 08 x OD 17 x Th 1.6mm |
| 11. | YN24S00010P1 | [1] | RELAY | KOBAlarm |
