纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-086[02]) - HARNESS ASSY, UPPER (FLOOR PLATE) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
379 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | PY01P01043D8 | [20] | CABLE TIE,102mm L | KOBWire Ties -- 368mm Long |
| 3. | YN13E01375P1 | [3] | CLIP,M8 x 8.20mm Shank | KOBAnchor Wire Ties |
| 5. | ZW26X08000 | [1] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 6. | ZN18C08007 | [1] | NUT | KOBM08x1.25mm |
| 7. | LQ13E01215P1 | [1] | PLATE | SM |
| 9. | ZW16P08000 | [1] | WASHER | KOBID 08 x OD 17 x Th 1.6mm |
| 10. | ZS18C08016 | [1] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| 12. | LQ13E01233P1 | [1] | GASKET | SM |
