纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-086[01]) - HARNESS ASSY, UPPER (FLOOR PLATE) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
410 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN13E01634P1 | [1] | WIRE HARNESS | SM |
| 2. | PY01P01043D8 | [8] | CABLE TIE,102mm L | KOBWire Ties -- 368mm Long |
| 3. | YN13E01375P1 | [6] | CLIP,M8 x 8.20mm Shank | KOBAnchor Wire Ties |
| 4. | LB13E01042P1 | [1] | WIRE HARNESS | SM |
| 13. | LB13E01040P1 | [1] | PLATE | KOB |
| 14. | ZW26X05000 | [12] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
