神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (07-004[02]) - MOTOR ASSEMBLY 2441U1054F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
525 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2441U1054F1 | [1] | HYDRAULIC MOTOR | KOBPROPEL |
| . . | LQ15V00004R100 | [1] | REPAIR KIT | KOBIncl 5 (4), 7 (5) |
| 1. | LQ15V00004S001 | [1] | CASE | KOB |
| 2. | LQ15V00004S002 | [1] | COVER | KOB |
| 3. | LQ15V00004S003 | [1] | CYLINDER | KOB |
| 4. | LQ15V00004S004 | [1] | SHOE | KOB |
| 5. | LQ15V00004S005 | [4] | PLATE | KOBPLATE Superseded by part number: LQ15V00004R100 |
| 6. | YN15V00003S006 | [1] | PISTON | KOB |
| 7. | 2441U783S7 | [5] | STEP PLATE | KOBPLATE, SEPARATE |
| 8. | LQ15V00004S008 | [1] | PLATE | KOB |
| 9. | LQ15V00004S009 | [1] | SHAFT | KOB |
| 10. | YN15V00003S010 | [1] | COUPLING | KOB |
| 11. | 2441U1054S011 | [1] | PLATE | |
| 12. | LQ15V00004S012 | [1] | BALL JOINT | KOB |
| 13. | 2441U1054S013 | [1] | HOLDER | |
| 14. | LQ15V00004S014 | [9] | PISTON ASSY | KOB Superseded by part number: LQ15V00004S014M |
| 15. | YN15V00003S015 | [1] | O-RING | KOB Superseded by part number: YN15V00017S063 |
| 16. | YN15V00003S016 | [1] | O-RING | KOB Superseded by part number: LS15V00004S052 |
| 17. | 2441U783S20 | [3] | CHECK VALVE | KOB |
| 18. | ZR26X06200 | [1] | SNAP RING | KOB |
| 19. | ZR26X08000 | [1] | SNAP RING | KOBRetaining -- ID 80 x OD 85.5 x Th 2.5mm |
| 20. | ZR16X04000 | [1] | RING | KOBRetaining -- ID 37 x OD 40 x Th 1.8mm |
| 21. | LQ15V00004S021 | [1] | PISTON | KOB |
| 22. | LQ15V00004S022 | [1] | BALL | KOB |
| 23. | LQ15V00004S023 | [2] | PLATE | KOB Superseded by part number: LQ15V00004S011 |
| 24. | YN15V00003S024 | [1] | SEAL | KOB |
| 25. | 2436U1123S14 | [1] | ORIFICE | KOB |
| 26. | 2436U812S4 | [1] | PLUG | PLUG |
| 27. | YN15V00003S027 | [1] | GASKET | KOB |
| 28. | 2441U783S30 | [3] | SPRING | KOB |
| 29. | LQ15V00004S029 | [9] | SPRING | KOB |
| 30. | YN15V00003S030 | [11] | SPRING | KOB |
| 31. | GB15V00003S029 | [1] | BEARING | KOB |
| 32. | LQ15V00004S032 | [1] | NEEDLE BEARING | KOB |
| 33. | ZS23C16045 | [8] | CAP,Hex Socket Head, M16 x 45mm | KOBScrew -- M16x2.0x45mm |
| 34. | ZP26D10022 | [1] | PIN | KOB |
| 35. | LQ15V00004S035 | [1] | O-RING | KOB |
| 36. | ZD12P00600 | [3] | O-RING | KOBID 05.80 ± 0.15 x OD 09mm |
| 37. | ZD12P00800 | [2] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 38. | ZD12P00900 | [3] | O-RING | KOBID 08.80 ± 0.17 x OD 12mm |
| 39. | YN15V00003S039 | [1] | O-RING | KOB |
| 40. | YN22V00013F1 | [2] | VALVE | KOB |
| 41. | 2436R874F1 | [1] | VALVE | KOB |
| 42. | YN23V00001F1 | [1] | BRAKE VALVE | KOB |
| 43. | ZR26X03200 | [1] | SNAP RING | KOBRetaining -- ID 32 x OD 34.4 x Th 1.2mm |
