神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (07-004[03]) - REDUCTION ASSEMBLY LQ15V00005F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
140 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LQ15V00005S001 | [1] | COVER | KOB |
| 2. | LQ15V00005S002 | [1] | CARRIER | KOB |
| 3. | LQ15V00005S003 | [3] | PIN | KOB |
| 4. | LQ15V00005S004 | [3] | BEARING | KOB |
| 5. | LQ15V00005S005 | [6] | WASHER | KOB |
| 6. | LQ15V00005S006 | [3] | GEAR | KOB |
| 7. | ZP26D04022 | [3] | PIN | KOB |
| 8. | LQ15V00005S008 | [1] | PLATE | KOB |
| 9. | LQ15V00005S009 | [1] | GEAR | KOB |
| 10. | LQ15V00005S010 | [1] | GEAR | KOB |
| 11. | LQ15V00005S013 | [3] | BEARING | KOB |
| 12. | LQ15V00005S014 | [3] | GEAR | KOB |
| 13. | LQ15V00005S016 | [6] | WASHER | KOB |
| 14. | LQ15V00005S017 | [1] | GEAR | KOB |
| 15. | LQ15V00005S018 | [1] | HOUSING | KOB |
| 16. | LQ15V00005S019 | [2] | BEARING | KOB |
| 17. | LQ15V00005S020 | [1] | SHIM | KOB |
| 18. | LQ15V00005S021 | [2] | LOCK WASHER | KOB |
| 19. | LQ15V00005S022 | [1] | RING | KOB |
| 20. | LQ15V00005S023 | [1] | SEAL | KOB Superseded by part number: ZD58F30040 |
| 21. | ZS23C10025 | [16] | SCREW,Hex Socket Head, M10 x 25mm | KOB Superseded by part number: ZS28C10025 |
| 22. | ZS23C16090 | [20] | SCREW,Hex Socket Head, M16 x 90mm | KOB |
| 23. | ZE82T12000 | [2] | PLUG | KOB |
| 24. | LQ15V00005S027 | [1] | CARRIER | KOB Superseded by part number: LQ15V00003F3 |
| 24. | LQ15V00003F3R | [1] | REMAN-HYD MOTOR | RACED190LC-6E BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292, Reman for New PN LQ15V00005S027 |
| 24. | LQ15V00003F3C | [1] | CORE-MOTOR HYDRAULIC | RACReturn Number |
| 25. | LQ15V00005S028 | [3] | PIN | KOB |
| 26. | ZP26D08036 | [3] | ROLL PIN | KOB |
