纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (13.011[003]) - MOTOR MOUNTING PARTS (S/N 11741-UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
889 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NS | [1] | NOT SERVICED | BASBEARING MOTOR SEE FIGURE 13.020/001 |
| 24. | 73186784 | [1] | ENGINE | BERMOTOR |
| 25. | 73177179 | [1] | FLANGE | BER Superseded by part number: 1292776 |
| 26. | 73176030 | [24] | SCREW,Hex Soc Hd, M10 x 35, 10.9 | BERCYL.HEAD SCREW Superseded by part number: 14420331 |
| 101. | 73177390 | [1] | BRACKET | BER Superseded by part number: 1294673 |
| 102. | 73177391 | [1] | ANGLE | BER Superseded by part number: 1294680 |
| 103. | 73183323 | [1] | BRACKET | BER Superseded by part number: 3001810 |
| 103. | 73189566 | [1] | BRACKET | BER Superseded by part number: 3023014 |
| 104. | 73179465 | [1] | SHIELD | BERAIR SHIELD Superseded by part number: 1293081 |
| 105. | 72181968 | [1] | CLIP | BER Superseded by part number: 70925620 |
| 110. | 73171677 | [2] | HYD CONNECTOR | BERSOCKET Superseded by part number: 73170944 |
| 111. | 73177393 | [1] | SPARE PART | NHSOCKET Superseded by part number: 73177394 |
| 112. | 73172487 | [2] | ADAPTER | BER Superseded by part number: 2979037 |
| 113. | 73172594 | [1] | TEMPERATURE SENDER | BERTEMP.TRANSMITTER Superseded by part number: 6911818 |
| 114. | 73170607 | [1] | DRAIN PLUG | BER Superseded by part number: 73179816 |
| 115. | 73174590 | [2] | BOLT,Hex, M12 x 16, 8.8, Full Thd | BERHEXAGON BOLT Superseded by part number: 388113 |
| 116. | 73170205 | [1] | BOLT,Hex, M8 x 16, 8.8 | BERHEXAGON BOLT Superseded by part number: 16043224 |
| 117. | 73177386 | [1] | PRESSURE SWITCH | BERPRESSUR.SWITCH Superseded by part number: 2781982 |
| 118. | 73170160 | [1] | WASHER | BERDISK/WASHER Superseded by part number: 86625263 |
| 119. | 73170161 | [1] | NUT,M8, Cl 8 | BERHEXAGON NUT Superseded by part number: 9706690 |
| 120. | 73170715 | [1] | WASHER | NHDISK/WASHER Superseded by part number: 84089872 |
