纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (13.230[001]) - INTAKE SYSTEM INSTALL.MATERIAL (S/N 11701-11740) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
773 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NS | [1] | NOT SERVICED | BASAIR FILTER MOUNTING PARTS SEE FIGURE 13.501/001 |
| 2. | 73177185 | [1] | ELBOW | BER Superseded by part number: 7225663 |
| 3. | 73177833 | [1] | HOSE | BERSUCTION HOSE Superseded by part number: 1293083 |
| 4. | 73172139 | [1] | HOSE CLIP | BER Superseded by part number: 2115623 |
| 5. | 73170938 | [1] | HOSE CLIP | BER Superseded by part number: 1740144 |
| 6. | 73170259 | [1] | HOSE CLIP | BER Superseded by part number: 2168074 |
| 8. | 73170780 | [4] | SCREW,Hex Soc Hd, M10 x 25, 8.8 | BERCYL.HEAD SCREW Superseded by part number: 120052 |
| 9. | 73170182 | [8] | WASHER | BERDISK/WASHER Superseded by part number: 84089817 |
| 10. | 73170215 | [4] | NUT | BERHEXAGON NUT Superseded by part number: 11701721 |
