凯斯零件查询(LB424R) - BALER (9/12-) (27.500.110) - LARGE STEERED TANDEM AXLE, SUSPENSION - FRANCE ONLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
536 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47403958
|
[1] |
SUPPORT
|
ZED
|
| 1. |
47403960
|
[1] |
SUPPORT
|
ZED
|
| 2. |
47403928
|
[2] |
SPRING
|
ZED
|
| 3. |
84100553
|
[4] |
SUPPORT
|
ZED
|
| 4. |
84100552
|
[4] |
INSULATOR BLOCK
|
ZED
|
| 5. |
84100555
|
[16] |
NUT
|
ZED
|
| 6. |
47403954
|
[2] |
SUPPORT
|
ZED
|
| 7. |
47404110
|
[8] |
BHD LOCK NUT
|
ZED
|
| 8. |
47403944
|
[4] |
U-BOLT
|
ZED
|
| 9. |
84100547
|
[4] |
SHIM
|
ZED
|
| 10. |
47403926
|
[2] |
SHAFT
|
ZED
|
| 11. |
84227805
|
[2] |
COTTER PIN
|
ZED
Superseded by part number: 84041875
|
| 12. |
84216778
|
[2] |
CROWN NUT
|
ZED
|
| 13. |
84100554
|
[8] |
BRIDGE
|
ZED
|
| 14. |
47404060
|
[4] |
BUSHING
|
ZED
|
