凯斯零件查询(LB424R) - BALER (9/12-) (27.500.120) - TANDEM FRONT AXLE, PNEUMATIC BRAKES - FRANCE ONLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
812 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47404145
|
[1] |
AXLE
|
ZED
|
| 2. |
84521823
|
[2] |
OIL SEAL
|
ZED
|
| 3. |
84100483
|
[2] |
BALL BEARING,75mm ID x 130mm OD x 33.25mm W
|
ZED
Superseded by part number: 26800210
|
| 4. |
84100482
|
[2] |
RING
|
ZED
|
| 5. |
84521825
|
[2] |
HUB
|
ZED
|
| 6. |
47404074
|
[2] |
BRAKE DRUM
|
ZED
|
| 7. |
84563584
|
[16] |
STUD
|
ZED
, Serial Range: -C084
|
| 7. |
47456247
|
[16] |
STUD
|
ZED
, Start Serial: D085
|
| 8. |
84100484
|
[2] |
RING
|
ZED
|
| 9. |
84100485
|
[2] |
BALL BEARING,60mm ID x 110mm OD x 29.75mm W
|
ZED
Superseded by part number: 87622924
|
| 10. |
84521828
|
[2] |
NUT
|
ZED
Superseded by part number: 84100486
|
| 11. |
84212727
|
[2] |
COTTER PIN
|
ZED
|
| 12. |
84521831
|
[2] |
COVER
|
ZED
|
| 13. |
14301931
|
[12] |
HEX SOC SCREW,M8 x 1.25 x 10mm, Cl 10.9, Full Thd
|
LEC
|
| 14. |
47404081
|
[4] |
BRAKE
|
ZED
|
| 15. |
47403925
|
[2] |
BRAKE SPRING
|
ZED
|
| 16. |
47404088
|
[1] |
CAMSHAFT
|
ZED
RIGHT
|
| 16. |
47404091
|
[1] |
CAMSHAFT
|
ZED
LEFT
|
| 17. |
47403947
|
[2] |
O-RING
|
ZED
|
| 18. |
47404056
|
[4] |
BRAKE
|
ZED
|
| 19. |
84100520
|
[2] |
CIRCLIP
|
ZED
Superseded by part number: 84568870
|
| 20. |
84014235
|
[2] |
SLEEVE
|
ZED
|
| 21. |
84100521
|
[2] |
PROTECTING COVER
|
ZED
|
| 22. |
84100527
|
[2] |
LEVER
|
ZED
|
| 23. |
84100529
|
[2] |
WASHER
|
ZED
|
| 24. |
84568347
|
[2] |
CIRCLIP,Ext
|
ZED
|
| 25. |
47404053
|
[4] |
BUSHING
|
ZED
|
| 26. |
47404066
|
[4] |
SPACER
|
ZED
|
| 27. |
47404102
|
[6] |
LOCK NUT
|
ZED
|
| 28. |
47404063
|
[2] |
SPACER
|
ZED
|
| 29. |
47403941
|
[2] |
WASHER
|
ZED
|
| 30. |
84214321
|
[2] |
LOCK WASHER
|
ZED
|
| 31. |
47404118
|
[2] |
LUBE NIPPLE
|
ZED
|
| 32. |
84568568
|
[2] |
LUBE NIPPLE
|
ZED
|
| 33. |
47404084
|
[2] |
PROTECTION PLATE
|
ZED
|
| 34. |
47404125
|
[1] |
FRONT AXLE
|
ZED
Incl 1 - 33, 35 - 41
|
| 35. |
84521844
|
[1] |
CROWN NUT
|
ZED
Incl 10, 11
|
| 36. |
84521845
|
[1] |
KIT
|
ZED
Incl 12, 13
|
| 37. |
47462799
|
[2] |
FIP KIT
|
ZED
Incl 7
|
| 38. |
84521846
|
[1] |
SEAL KIT
|
ZED
Incl 2, 4, 8
|
| 39. |
47404176
|
[2] |
FIP KIT
|
ZED
Incl 14, 15, 25
|
| 40. |
47404193
|
[1] |
FIP KIT
|
ZED
Incl 17 - 21, 31, 32
|
| 41. |
47404195
|
[2] |
FIP KIT
|
ZED
Incl 27, 30, 33
|
