| 1. |
47403948
|
[1] |
AXLE
|
ZED
|
| 2. |
47403950
|
[1] |
ARM
|
ZED
RIGHT
|
| 2. |
47403952
|
[1] |
ARM
|
ZED
LEFT
|
| 3. |
84014235
|
[2] |
SLEEVE
|
ZED
|
| 4. |
47404056
|
[4] |
BRAKE
|
ZED
|
| 5. |
47404053
|
[2] |
BUSHING
|
ZED
|
| 6. |
47404081
|
[4] |
BRAKE
|
ZED
|
| 7. |
84100521
|
[2] |
PROTECTING COVER
|
ZED
|
| 8. |
47403947
|
[2] |
O-RING
|
ZED
|
| 9. |
84563584
|
[16] |
STUD
|
ZED
, Serial Range: -C084
|
| 9. |
47456247
|
[16] |
STUD
|
ZED
, Start Serial: D085
|
| 10. |
47404074
|
[2] |
BRAKE DRUM
|
ZED
|
| 11. |
84521823
|
[2] |
OIL SEAL
|
ZED
|
| 12. |
84100482
|
[2] |
RING
|
ZED
|
| 13. |
84521825
|
[2] |
HUB
|
ZED
|
| 14. |
84100484
|
[2] |
RING
|
ZED
|
| 15. |
84521912
|
[1] |
SPACER
|
ZED
|
| 16. |
84521828
|
[2] |
NUT
|
ZED
Superseded by part number: 84100486
|
| 17. |
84212727
|
[2] |
COTTER PIN
|
ZED
|
| 18. |
14301931
|
[12] |
HEX SOC SCREW,M8 x 1.25 x 10mm, Cl 10.9, Full Thd
|
LEC
|
| 19. |
84521831
|
[2] |
COVER
|
ZED
|
| 20. |
84100485
|
[2] |
BALL BEARING,60mm ID x 110mm OD x 29.75mm W
|
ZED
Superseded by part number: 87622924
|
| 21. |
84100483
|
[2] |
BALL BEARING,75mm ID x 130mm OD x 33.25mm W
|
ZED
Superseded by part number: 26800210
|
| 22. |
47404088
|
[1] |
CAMSHAFT
|
ZED
RIGHT
|
| 22. |
47404091
|
[1] |
CAMSHAFT
|
ZED
LEFT
|
| 23. |
336199
|
[10] |
BOLT,Hex, M8 x 1.25 x 12mm, Cl 8.8, Full Thd
|
NH
Superseded by part number: 16043024
|
| 24. |
80681
|
[10] |
LOCK NUT,5/16"
|
NH
Superseded by part number: 83990583
|
| 25. |
84215200
|
[2] |
CAP
|
ZED
|
| 26. |
87747217
|
[2] |
SHAFT
|
ZED
|
| 27. |
84216293
|
[2] |
BUSHING
|
ZED
|
| 28. |
84216291
|
[2] |
BUSHING
|
ZED
|
| 29. |
84216296
|
[4] |
WASHER
|
ZED
|
| 30. |
84216320
|
[2] |
O-RING
|
ZED
|
| 31. |
84215201
|
[2] |
RING NUT
|
ZED
|
| 32. |
84025751
|
[4] |
LOCK PIN,M6 x 12, Slotted
|
ZED
|
| 33. |
84215199
|
[2] |
CAP
|
ZED
|
| 34. |
300442
|
[2] |
HEX SOC SCREW,M10 x 30mm, Cl 8.8
|
GI
Superseded by part number: 87016471
|
| 35. |
84100520
|
[2] |
CIRCLIP
|
ZED
Superseded by part number: 84568870
|
| 36. |
16440421
|
[1] |
BOLT,Hex, M20 x 2.5 x 200mm, Cl 8.8
|
BRR
|
| 37. |
84568568
|
[2] |
LUBE NIPPLE
|
ZED
|
| 38. |
47404092
|
[1] |
DRAG LINK
|
ZED
|
| 39. |
84100527
|
[2] |
LEVER
|
ZED
|
| 40. |
84568347
|
[2] |
CIRCLIP,Ext
|
ZED
|
| 41. |
84100595
|
[1] |
BUSHING
|
ZED
|
| 42. |
84100596
|
[2] |
STEERING CYLINDER
|
ZED
|
| 43. |
47403962
|
[1] |
SUPPORT
|
ZED
RIGHT
|
| 43. |
47404049
|
[1] |
SUPPORT
|
ZED
LEFT
|
| 44. |
84100593
|
[1] |
BUSHING
|
ZED
|
| 45. |
84100594
|
[4] |
WASHER
|
ZED
|
| 46. |
412180
|
[6] |
NUT,M20 x 2.5, Cl 8
|
ZED
Superseded by part number: 9672396
|
| 47. |
84100592
|
[1] |
SHOCK ABSORBER
|
ZED
|
| 48. |
84100597
|
[2] |
SCREW
|
ZED
|
| 49. |
126699A1
|
[3] |
CONVEYOR
|
CAS
|
| 50. |
84521909
|
[1] |
BOLT,Hex, M20 x 2.5 x 210mm
|
ZED
|
| 51. |
84100598
|
[2] |
LOCK NUT
|
ZED
|
| 52. |
47403925
|
[2] |
BRAKE SPRING
|
ZED
|
| 53. |
84100529
|
[2] |
WASHER
|
ZED
|
| 54. |
47404066
|
[2] |
SPACER
|
ZED
|
| 55. |
47404102
|
[4] |
LOCK NUT
|
ZED
|
| 56. |
47404063
|
[2] |
SPACER
|
ZED
|
| 57. |
47403941
|
[4] |
WASHER
|
ZED
|
| 58. |
84214321
|
[2] |
LOCK WASHER
|
ZED
|
| 59. |
47404084
|
[2] |
PROTECTION PLATE
|
ZED
|
| 60. |
47404118
|
[2] |
LUBE NIPPLE
|
ZED
|
| 61. |
47404130
|
[1] |
REAR AXLE
|
ZED
Incl 1 - 60, 62 - 71
|
| 62. |
84521844
|
[1] |
CROWN NUT
|
ZED
Incl 16, 17
|
| 63. |
84521845
|
[1] |
KIT
|
ZED
Incl 18, 19
|
| 64. |
47462799
|
[2] |
FIP KIT
|
ZED
Incl 9
|
| 65. |
84521846
|
[1] |
SEAL KIT
|
ZED
Incl 11, 12, 14
|
| 66. |
47404176
|
[2] |
FIP KIT
|
ZED
Incl 5, 6, 52
|
| 67. |
47404193
|
[1] |
FIP KIT
|
ZED
Incl 3, 4, 7, 8, 35, 37, 60
|
| 68. |
47404195
|
[2] |
FIP KIT
|
ZED
Incl 55, 58, 59
|
| 69. |
84215225
|
[1] |
KIT
|
ZED
Incl 27, 28
|
| 70. |
84215226
|
[1] |
KIT
|
ZED
Incl 23 - 25, 30, 33
|
| 71. |
84215228
|
[2] |
KIT
|
ZED
Incl 26, 29, 31, 32, 34
|
