纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (20.310[004]) - HYDRAULIC SYSTEM HIGH PRESSURE HAMMER (OPTION) (S/N 11701-UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
536 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NS | [1] | NOT SERVICED | BASTREADLE VALVE INSTALL.MATERIAL SEE FIGURE 23.290/001 |
| 3. | 73180449 | [1] | BRACKET | BER Superseded by part number: 3001314 |
| 10. | 73178496 | [1] | 3 WAY CONNECTION | BERSHUTTLE VALVE Superseded by part number: 1758358 |
| 11. | 73176465 | [1] | HYDRAULIC VALVE | BERVALVE Superseded by part number: 1252940 |
| 12. | 73171650 | [1] | O-RING | BER Superseded by part number: 42132 |
| 13. | 73179961 | [2] | SCREW | BERTHREADED ROD Superseded by part number: 2250525 |
| 15. | 73170341 | [2] | SEALING RING | BERSEALING RING Superseded by part number: 1725417 |
| 16. | 73170342 | [8] | 12 PT SCREW | BER12-POINT SCREW Superseded by part number: 1741263 |
| 17. | 73170346 | [2] | O-RING | BERSEALING RING Superseded by part number: 1725419 |
| 18. | 73170347 | [8] | 12 PT SCREW | BER12-POINT SCREW Superseded by part number: 1265073 |
| 25. | 73179478 | [1] | CLIP | BER Superseded by part number: 1275490 |
| 26. | 73180450 | [1] | CLIP | BER Superseded by part number: 1298934 |
| 27. | 73179480 | [1] | CLIP | BER Superseded by part number: 1275627 |
| 151. | 73179418 | [1] | HOSE | BER Superseded by part number: 1285655 |
| 154. | 73179419 | [1] | HOSE | BER Superseded by part number: 1283469 |
| 155. | 73175614 | [1] | HOSE | BER Superseded by part number: 1258859 |
| 400. | 73182604 | [1] | HOSE | BER Superseded by part number: 3001440 |
| 442. | 73179485 | [1] | HOSE | BER Superseded by part number: 1294436 |
| 443. | 73187450 | [1] | FLEXIBLE HOSE | BERHOSE Superseded by part number: 3001441 |
