纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (20.310[003]) - HYDRAULIC SYSTEM HIGH PRESSURE HAMMER (S/N 11702-UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
242 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NS | [1] | NOT SERVICED | BASCONTROL BLOCK MOUNTING PARTS HAMMER SEE FIGURE 23.611/004 |
| 9. | 73176464 | [2] | BOLT,Hex, M6 x 170, 8.8 | BERHEXAGON BOLT Superseded by part number: BRR2426425 |
| 10. | 73180322 | [2] | PLUG | BERSCREWING Superseded by part number: 7723930 |
| 26. | 73170341 | [2] | SEALING RING | BERSEALING RING Superseded by part number: 1725417 |
| 27. | 73170342 | [8] | 12 PT SCREW | BER12-POINT SCREW Superseded by part number: 1741263 |
| 28. | 73170327 | [1] | RING | BERSEALING RING Superseded by part number: 1725418 |
| 29. | 73170470 | [4] | SCREW | BER12-POINT SCREW Superseded by part number: 1183269 |
| 143. | 73178499 | [1] | HOSE | BER Superseded by part number: 1283428 |
| 153. | 73179419 | [1] | HOSE | BER Superseded by part number: 1283469 |
| 243. | 73176456 | [1] | HOSE | BER Superseded by part number: 1258327 |
| 244. | 73171810 | [1] | HOSE | NH Superseded by part number: 73171811 |
| 401. | 73180323 | [1] | HOSE | BER Superseded by part number: 3001317 |
| 430. | 73179484 | [1] | HOSE | BER Superseded by part number: 1296332 |
