纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (20.610[001]) - HYDRAULIC SYSTEM SERVO CONTROL HAMMER (OPTION) (S/N 11701-UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
475 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | NS | [1] | NOT SERVICED | BASTREADLE VALVE INSTALL.MATERIAL SEE FIGURE 23.290/001 |
| 4. | 73170415 | [2] | BOLT,Hex, M6 x 125, 8.8 | BERHEXAGON BOLT Superseded by part number: BRR2292390 |
| 8. | 73178496 | [1] | 3 WAY CONNECTION | BERSHUTTLE VALVE Superseded by part number: 1758358 |
| 143. | 73178499 | [1] | HOSE | BER Superseded by part number: 1283428 |
| 151. | 73179418 | [1] | HOSE | BER Superseded by part number: 1285655 |
| 153. | 73179419 | [1] | HOSE | BER Superseded by part number: 1283469 |
