纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (20.600[004]) - HYDRAULIC SYSTEM BOOM CYLINDERS (S/N 12058-UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
342 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 11. | 73188410 | [1] | TUBE,22 mm OD, 360, 160 mm Length | BERPIPE Superseded by part number: 3007572 |
| 12. | 73188411 | [1] | TUBE,22 mm OD, 360, 160 mm Length | BERPIPE Superseded by part number: 3007573 |
| 13. | 73170341 | [2] | SEALING RING | BERSEALING RING Superseded by part number: 1725417 |
| 14. | 73170342 | [8] | 12 PT SCREW | BER12-POINT SCREW Superseded by part number: 1741263 |
| 15. | 73188412 | [1] | FITTING | BERNIPPLE Superseded by part number: 1148456 |
