凯斯零件查询(LB424R) - BALER (9/12-) (35.565.010) - KNIFE DRAWER, HYDRAULICS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
264 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84355748
|
[1] |
CORE-HYD CYLINDER,Double Acting, 25mm Rod, 121.5mm Stroke
|
ZED
Incl 2
|
| 2. |
84053275
|
[1] |
SEAL KIT
|
ZED
|
| 3. |
9850761
|
[1] |
CLEVIS PIN,M16 x 60
|
ZED
|
| 4. |
412685
|
[1] |
COTTER PIN,M4 x 32
|
ZED
|
| 5. |
378246
|
[2] |
WASHER,17mm ID x 34mm OD x 3mm Thk
|
ZED
|
| 6. |
9501786
|
[1] |
PIN,20mm OD x 100mm L
|
LEC
|
| 7. |
378247
|
[9] |
WASHER,21mm ID x 39mm OD x 3mm Thk
|
ZED
|
| 8. |
412686
|
[1] |
COTTER PIN,M5 x 32
|
NH
|
| 9. |
84037257
|
[2] |
HYD CONNECTOR
|
ZED
|
