| 1. |
84299834
|
[1] |
HYD TUBE
|
ZED
, Serial Range: -C150
|
| 1. |
47968288
|
[1] |
HYD TUBE
|
ZED
, Start Serial: D151
|
| 1. |
84287869
|
[1] |
HYD TUBE
|
ZED
, Serial Range: -C150
|
| 1. |
47968284
|
[1] |
HYD TUBE
|
ZED
, Start Serial: D151
|
| 2. |
84299832
|
[1] |
HYD TUBE
|
ZED
, Serial Range: -C150
|
| 2. |
47968286
|
[1] |
HYD TUBE
|
ZED
, Start Serial: D151
|
| 2. |
84287867
|
[1] |
HYD TUBE
|
ZED
, Serial Range: -C150
|
| 2. |
47968282
|
[1] |
HYD TUBE
|
ZED
, Start Serial: D151
|
| 3. |
84287259
|
[1] |
HYD TUBE
|
ZED
|
| 4. |
386215
|
[2] |
HYD CONNECTOR
|
ZED
|
| 5. |
87479525
|
[1] |
FITTING
|
PLO
|
| 6. |
84595959
|
[1] |
HYD TUBE
|
ZED
|
| 6. |
84595965
|
[1] |
HYD TUBE
|
ZED
|
| 7. |
87493574
|
[3] |
NUT
|
ZED
|
| 8. |
87734612
|
[1] |
HYD CONNECTOR
|
ZED
|
| 9. |
87492506
|
[1] |
FLEXIBLE HOSE,6.3mm ID x 2500mm L, SAE 100R1
|
ZED
, Serial Range: -C162
|
| 9. |
48021939
|
[1] |
HYDRAULIC HOSE
|
ZED
White, Start Serial: D163
|
| 10. |
430357
|
[12] |
CLAMP
|
DUB
|
| 11. |
431941
|
[6] |
SUPPORT
|
DUB
|
| 12. |
84595955
|
[1] |
HYD TUBE
|
ZED
|
| 12. |
84595961
|
[1] |
HYD TUBE
|
ZED
|
| 13. |
84292377
|
[1] |
HYD TUBE
|
ZED
|
| 13. |
84287873
|
[1] |
HYD TUBE
|
ZED
|
| 14. |
433008
|
[10] |
CLAMP
|
NH
|
| 15. |
379430
|
[1] |
3 WAY CONNECTION
|
ZED
|
| 16. |
418283
|
[1] |
ELBOW
|
ZED
|
| 17. |
87474977
|
[1] |
HYD TUBE,8 mm DIA x 40 mm L
|
ZED
|
| 18. |
84062569
|
[1] |
DRAINCOCK/TAP SUPPLY,M14 x 1.5 x M14 x 1.5
|
ZED
|
| 19. |
433101
|
[5] |
SUPPORT
|
NH
|
| 20. |
434097
|
[1] |
SUPPORT
|
DUB
|
| 21. |
86588450
|
[10] |
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
|
ZED
|
| 22. |
120056
|
[9] |
BOLT,M6 x 1.0 x 54.15mm, Cl 8.8
|
NH
|
| 23. |
412152
|
[10] |
NUT,M6 x 1, Cl 8.8
|
ZED
|
| 24. |
84542431
|
[1] |
HYD TUBE
|
ZED
|
| 24. |
84542433
|
[1] |
HYD TUBE
|
ZED
|
| 25. |
335172
|
[2] |
HYD CONNECTOR,M14 x 1.5 x M14 x 1.5
|
ZED
|
| 26. |
84819676
|
[2] |
PROTECTION CAP
|
ZED
|
| 27. |
84308910
|
[2] |
HOSE,6.35mm ID x 1500mm L, SAE 100R1
|
ZED
|
| 27. |
84292648
|
[2] |
HOSE,6.35mm ID x 1670mm L, SAE 100R1
|
ZED
|
| 28. |
84819675
|
[2] |
PUSH-PULL COUPLING
|
ZED
|
| 29. |
84595957
|
[1] |
HYD TUBE
|
ZED
|
| 29. |
84595963
|
[1] |
HYD TUBE
|
ZED
|
| 30. |
430356
|
[2] |
CLAMP
|
ZED
|
| 31. |
84814948
|
[1] |
SUPPORT
|
ZED
|
| 32. |
292267
|
[1] |
LAMP
|
ZED
L= 1M Superseded by part number: 80292267
|
| 33. |
43118
|
[3] |
BOLT,Hex, M6 x 1.0 x 40mm, Cl 8.8
|
NH
Superseded by part number: 120102
|
| 34. |
84350868
|
[2] |
HYD TUBE,6.35mm ID x 1120mm L, SAE 100R16
|
ZED
|
| 35. |
84041508
|
[2] |
HYD CONNECTOR
|
ZED
|
| 36. |
9507811
|
[1] |
CONDUIT
|
CUR
L= 2M, Start Serial: D072 Superseded by part number: 9507811BR
|
| 37. |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
, Start Serial: D137
|
| 38. |
87716662
|
[2] |
NUT
|
ZED
, Serial Range: -F137150
|
| 38. |
84578718
|
[2] |
RIVET,Flng, 9mm OD x 18mm L
|
ZED
, Start Serial: D151
|
| 39. |
48021940
|
[1] |
HYDRAULIC HOSE
|
ZED
Black, Start Serial: D163
|
