凯斯零件查询(LB424R) - BALER (9/12-) (35.570.010) - ROLLER BALE CHUTE, CYLINDER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
579 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84272153
|
[1] |
HYDRAULIC CYLINDER,Double Acting, 20mm Rod, 550mm Stroke
|
ZED
Incl 2, 9-11, Serial Range: -C146
|
| 1. |
84300618
|
[1] |
HYDRAULIC CYLINDER
|
ZED
Incl 2, Start Serial: D147
|
| 1. |
84272153R
|
[1] |
REMAN-HYD CYLINDER
|
ZED
|
| 1. |
84272153C
|
[1] |
CORE-HYD CYLINDER
|
ZED
Return Number
|
| 2. |
84299533
|
[1] |
SEAL KIT
|
ZED
, Serial Range: -C146
|
| 2. |
47722310
|
[1] |
SEAL
|
PLO
, Start Serial: D147
|
| 3. |
84400935
|
[1] |
ROLLER
|
ZED
, Serial Range: -C146
|
| 3. |
47931704
|
[1] |
ROLLER
|
ZED
, Start Serial: D147
|
| 4. |
356015
|
[1] |
SPINDLE
|
ZED
, Serial Range: -C146
|
| 4. |
412109
|
[1] |
PIN
|
ZED
, Start Serial: D147
|
| 5. |
378246
|
[1] |
WASHER,17mm ID x 34mm OD x 3mm Thk
|
ZED
|
| 6. |
84814924
|
[2] |
WASHER,16.3mm ID x 31.5mm OD x 1.25mm Thk
|
ZED
|
| 7. |
130007
|
[3] |
COTTER PIN,M4 x 25
|
NH
Superseded by part number: 83903970
|
| 8. |
84078725
|
[1] |
CLEVIS PIN,16mm OD x 100mm L
|
ZED
, Serial Range: -C146
|
| 8. |
47931819
|
[1] |
PIN
|
ZED
, Start Serial: D147
|
| 9. |
322358
|
[1] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
, Serial Range: -C146
|
| 10. |
43235
|
[1] |
BOLT,Hex, M8 x 1.25 x 30mm, Cl 10.9, Full Thd
|
BHB
, Serial Range: -C146
|
| 11. |
84292649
|
[1] |
CHECK VALVE
|
ZED
, Serial Range: -C146
|
