凯斯零件查询(LB424R) - BALER (9/12-) (35.568.010) - FEED CHAMBER, CYLINDER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
371 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84807175
|
[2] |
HYDRAULIC CYLINDER,Double Acting, 20mm Rod, 235mm Stroke
|
ZED
Incl 8
|
| 2. |
87344037
|
[2] |
CLEVIS PIN,M12 x 90
|
ZED
Superseded by part number: 86639103
|
| 3. |
378245
|
[10] |
WASHER,13mm ID x 28.5mm OD x 2.7mm Thk
|
NH
|
| 4. |
130003
|
[2] |
COTTER PIN,3mm OD x 30mm OAL
|
ZED
|
| 5. |
325829
|
[2] |
BOLT,Hex, M10 x 1.5 x 45mm, Cl 8.8
|
NH
Superseded by part number: 56614
|
| 6. |
100037
|
[2] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 7. |
916612
|
[2] |
BREATHER
|
ZED
|
| 8. |
84026460
|
[1] |
SEAL KIT
|
ZED
|
