纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (23.270[003]) - SERVO VALVE INSTALL.MATERIAL LEFT-HAND (S/N 12022-UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
787 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NS | [1] | NOT SERVICED | BASSERVO VALVE MOUNTING PARTS LEFT-HAND SEE FIGURE 23.271/003 |
| 3. | 73170380 | [4] | HYD CONNECTOR | BERSOCKET Superseded by part number: 73170381 |
| 4. | 73170656 | [2] | SWIVEL CONNECTION | BERSWING FIXTURE Superseded by part number: 1768202 |
| 6. | 73171233 | [4] | HEX SOC SCREW,Flat Hd, M6 x 12mm, Cl 8.8 | BERCONTER-SUNK SCREW Superseded by part number: 2479103 |
