纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (23.271[001]) - SERVO VALVE MOUNTING PARTS LEFT-HAND (S/N 11701-12021) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
772 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 73171336 | [1] | CONTROL VALVE | BERSERVO VALVE Superseded by part number: 2496568, 2455625, 2496570, 73176177, 2458294, 1478148 |
| 4. | 73176032 | [1] | HANDLE | BER Superseded by part number: 2458294 |
| 50. | 73176033 | [1] | CAP | BERRUBBER CAP Superseded by part number: 1474783 |
| 51. | 73176034 | [1] | CAP | BERRUBBER CAP Superseded by part number: 1474782 |
| 100. | 73176176 | [1] | BODY | BERVALVE BODY Superseded by part number: 1478148 |
| 103. | NS | [4] | NOT SERVICED | BASSERVO VALVE SEE FIGURE 23.272/001 |
| 106. | 73176035 | [1] | PLUG | BERSCREW PLUG Superseded by part number: 1445973 |
| 203. | 73176036 | [1] | PLATE | BERSWITCH Superseded by part number: 1445986 |
| 205. | 73176037 | [1] | NUT | BEREXTENSION Superseded by part number: 1445987 |
| 206. | 73176038 | [1] | BELLOWS | BER Superseded by part number: 2455625 |
| 210. | 73176039 | [1] | SCREW | BERCYL.HEAD SCREW Superseded by part number: 864-5016 |
