| . . | 24100J1997F2 | [1] | ATT SUBASSY, HOE, CONSISTS OF REF. 7 TO 39 | |
| 7. | 2419P738 | [2] | PIN | KOBPIN |
| 8. | 2419P739D2 | [2] | PIN | KOBPIN |
| 9. | 2419P740 | [1] | PIN | |
| 11. | 2419P769D1 | [1] | PIN | KOBPIN Superseded by part number: 2419P1306 |
| 12. | 2419P769D2 | [1] | PIN | KOBPIN Superseded by part number: 2419P1222 |
| 13. | 2419P960F1 | [4] | PIN | KOBPIN INCL. REF. 13-5 |
| 13-5. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 14. | 2419T1489 | [7] | PIN | PIN |
| 16. | R20T0022 | [1] | NUT | KOBNUT |
| 17. | ZW11X36000 | [1] | WASHER | |
| 18. | 2418T3986 | [1] | COLLAR | KOBCOLLAR |
| 19. | ZP15D05035 | [7] | COTTER PIN | KOBPIN Cotter Superseded by part number: ZP15D05080 |
| 20. | ZP15D06065 | [1] | BASE PLATE | BASE PLATE |
| 21. | ZS12C12085 | [4] | SCREW,Hex, M12 x 85mm | KOB Superseded by part number: ZS13C12085 |
| 22. | ZN12C12010 | [8] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 23. | 4018T183D1 | [8] | SHIM,52mm ID x 80mm OD x 2.3mm Thk | KOBSHIM, 2.3 Superseded by part number: B16T0442D24 |
| 24. | 4018T183D2 | [8] | SHIM,52mm ID x 80mm OD x 1.2mm Thk | KOBSHIM, 1.2 Superseded by part number: B16T0442D25 |
| 25. | 2418T4038D2 | [8] | SHIM, 1.2 | SHIM, 1.2 |
| 26. | 2418T4038D1 | [8] | SHIM | KOB |
| 27. | 2418T4038D5 | [8] | SHIM | KOB |
| 28. | 4018T98D2 | [4] | SHIM | KOB1.2 |
| 29. | 4018T98D1 | [4] | SHIM | KOB2.3 |
| 30. | 2420T2571D1 | [4] | SHIM,62mm ID x 120mm OD x 3.2mm Thk | KOBSHIM, 3.2 ID 62 x OD 120 x Th 3.2mm |
| 31. | 2420T2571D2 | [4] | SHIM,62mm ID x 120mm OD x 4.5mm Thk | KOBSHIM |
| 32. | 2411J1030F1 | [1] | BOOM, INCL. REF. 32-35 TO 32-37 | |
| 32-35. | 2405T593C2 | [2] | BUSHING | KOB |
| 32-36. | 2445R138D3 | [4] | SEAL,60mm ID x 75mm OD x 4mm Thk | KOBDust -- ID 60 x OD 75 x Th 4mm |
| 32-37. | ZG91S02000 | [2] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 33. | 24UJ1031F1 | [1] | ARM | |
| 33-21. | 2405T595C2 | [2] | BUSHING | KOBINCL. REF 33-21 TO 33-25 BUSHING |
| 33-22. | 2405T594C2 | [4] | BUSHING | KOB |
| 33-23. | 2445R138D3 | [2] | SEAL,60mm ID x 75mm OD x 4mm Thk | KOBDust -- ID 60 x OD 75 x Th 4mm |
| 33-21. | 2445R138D1 | [4] | SEAL,50mm ID x 65mm OD x 4mm Thk | KOBDust -- ID 50 x OD 65 x Th 4mm |
| 33-25. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 34. | 2406P1590D1 | [1] | LINK, IDLER | |
| 35. | 2406P1590D2 | [1] | LINK, IDLER | |
| 37. | 2419P742D3 | [1] | PIN | |
| 38. | 2406P166701F1 | [1] | LINK, BUCKET | |
| 38-4. | 2405T596C2 | [2] | BUSHING | KOBINCL. REF. 38-4 & 38-5 BUSHING |
| 38-5. | 2445R138D1 | [4] | SEAL,50mm ID x 65mm OD x 4mm Thk | KOBDust -- ID 50 x OD 65 x Th 4mm |
| 39. | 2406P1667D2F1 | [1] | LINK, BUCKET | |
| 39-4. | 2405T596C2 | [2] | BUSHING | KOBINCL. REF. 39-4 & 39-5 BUSHING |
| 39-5. | 2445R138D1 | [4] | SEAL,50mm ID x 65mm OD x 4mm Thk | KOBDust -- ID 50 x OD 65 x Th 4mm |
