神钢零件查询(K903A) - EXCAVATOR BTW K2748 - K3928 (1/76-12/03) (09-012) - INSTAL, CRAWLER TRACK, P/N 24100J117F9, F10, F11 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
133 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J1117F9 | [1] | INSTAL CRAWLER TRACK, CONSISTS OF REF 2 TO 9 | |
| . . | 24100J1117F10 | [1] | INSTAL CRAWLER TRACK, CONSISTS OF REF 2 TO 9 | |
| . . | 24100J1117F11 | [1] | INSTAL CRAWLER TRACK, CONSISTS OF REF 2 TO 9 | |
| 2. | 2420T2611 | [336] | BOLT | |
| 3. | 4020Z5 | [336] | NUT | KOBNUT Superseded by part number: 2420T3917 |
| 5. | 2424N102D2 | [84] | TRACK SHOE | KOB500, F9 ONLY |
| 6. | 2424N1102D3 | [84] | SHOE, 600, F10 ONLY | |
| 7. | 2424J104 | [84] | SHOE, 400, F11 ONLY | |
| 9. | 24100J1118F4 | [2] | CONSISTS OF REF. 9-1 TO 9-10 | |
| 9-1. | 2424J103D1 | [42] | TRACK LINK | |
| 9-2. | 2424J103D2 | [42] | TRACK LINK | |
| 9-3. | 2405P182 | [40] | BUSHING | KOB |
| 9-5. | 2405P183 | [2] | BUSHING | KOB Superseded by part number: YT62D01003P1 |
| 9-7. | 2418T3592 | [4] | COLLAR | KOB |
| 9-9. | 2419P749C2 | [40] | PIN,TRACK | PIN,TRACK |
| 9-10. | 2419P915C2 | [2] | PIN | KOB |
