纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (23.610[002]) - CONTROL BLOCK INSTALL.MATERIAL (S/N 11701-12057) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
652 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NS | [1] | NOT SERVICED | BASCONTROL BLOCK MOUNTING PARTS SEE FIGURE 23.611/003 |
| 52. | 73171679 | [4] | SPACER | BER Superseded by part number: 39899 |
| 53. | 73172067 | [4] | BOLT,Hex, M12 x 110, 10.9 | BERHEXAGON BOLT Superseded by part number: 9501756 |
| 54. | 73170169 | [4] | WASHER | BERDISK/WASHER Superseded by part number: 84089818 |
| 55. | 73170922 | [4] | LOCK NUT,M12 x 1.75, Cl 10 | BERHEXAGON NUT Superseded by part number: 412672 |
