纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (23.610[003]) - CONTROL BLOCK INSTALL.MATERIAL (S/N 12058-UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
283 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NS | [1] | NOT SERVICED | BASCONTROL BLOCK MOUNTING PARTS SEE FIGURE 23.611/005 |
| 52. | 73188244 | [4] | SPACER | BERSLEEVE Superseded by part number: 3022166 |
| 53. | 73189593 | [4] | SCREW | BERHEXAGON BOLT Superseded by part number: 86508622 |
| 54. | 73176758 | [4] | WASHER | BERDISK/WASHER Superseded by part number: 86625255 |
| 55. | 73170922 | [4] | LOCK NUT,M12 x 1.75, Cl 10 | BERHEXAGON NUT Superseded by part number: 412672 |
