| . . | 24100X826F3 | [1] | CONTROL ASSY, CONSISTS OF REF. 1 TO 75 | |
| 1. | 24100J2456F1 | [1] | LEVER ASSY, CONTROL | |
| 6. | 2420P964D6 | [2] | ROD | |
| 11. | 24100N879F2 | [1] | LOCK ASSY, SWING, CONSISTS OF REF. 11-1 TO 11-9 | |
| 11-1. | 2419T1734 | [1] | PIN | PIN |
| 11-3. | 2414T819 | [1] | COVER | KOB |
| 11-4. | ZS16C06014 | [4] | SCREW | KOBM06x1.0x16mm Superseded by part number: ZS18C06014 |
| 11-5. | ZW22X06000 | [4] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 11-6. | 2418T4228 | [1] | WASHER | |
| 11-7. | ZP15D03020 | [2] | SPLIT PIN | KOBCOTTER |
| 11-8. | ZW11X16000 | [1] | WASHER | KOBID 16 x OD 30 x Th 2.3mm |
| 11-9. | 2420T2642D4 | [1] | ROD | |
| 14. | ZN31F12011 | [6] | NUT | KOB |
| 15. | ZN12F12007 | [14] | NUT | KOBM12x1.25mm Superseded by part number: ZN17F12007 |
| 16. | B20T0013D2 | [1] | ROD | |
| 17. | R06T0011 | [6] | ROD-END JOINT. BALL | ROD-END JOINT. BALL |
| 18. | 2406Z215 | [8] | ROD | KOBROD, END |
| 19. | 2420Z681 | [6] | ROD | KOBEND |
| 20. | 2425R145D1 | [4] | BLOCK | |
| 21. | 2406P1653D1 | [1] | PEDAL | |
| 22. | 2406P1653D2 | [1] | PEDAL | |
| 23. | R16P0105 | [2] | CLAMP | CLAMP |
| 24. | ZM11C10025 | [10] | BOLT | KOBM10x1.50x25mm (Incls. Lockwasher) Superseded by part number: ZM12C10025 |
| 25. | ZW26X10000 | [10] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 26. | ZS16C10055 | [4] | CAPSCREW M10x1.50x55mm | CAPSCREW M10x1.50x55mm |
| 27. | ZN16C10008 | [16] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 28. | ZN11C08007 | [24] | NUT | KOBM08x1.25mm Superseded by part number: ZN16C08007 |
| 29. | ZM11C10030 | [12] | SCREW | KOBM10x1.50x30mm (Incls. Lockwasher) |
| 30. | 2406P1596D1 | [1] | LINK | |
| 31. | 2406P1596D2 | [1] | LINK | |
| 32. | ZP45X12032 | [1] | PIN | KOBPIN |
| 33. | ZW11X12000 | [14] | WASHER | KOBID 12 x OD 24 x Th 2.3mm Superseded by part number: ZW16X12000 |
| 34. | ZP15D04020 | [8] | BASE PLATE Pin, Cotter | BASE PLATE Pin, Cotter |
| 35. | ZS12C08025 | [8] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 36. | ZW22X08000 | [12] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 37. | ZW11X08000 | [8] | WASHER | KOBID 09 x OD 17 x Th 1.6mm Superseded by part number: ZW16X08000 |
| 38. | 2418P4691 | [1] | PLATE | |
| 39. | 2406T1188 | [4] | YOKE | |
| 40. | 2406T1187D1 | [8] | LINK | |
| 41. | ZW13H12000 | [6] | WASHER | KOB |
| 42. | B20P0005D63 | [1] | ROD | |
| 43. | 2420P1142D1 | [1] | ROD | |
| 44. | 2416P4498 | [1] | BRACKET | |
| 48. | ZN11C12010 | [4] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 49. | ZN12F12010 | [8] | NUT | NUT |
| 50. | R06P0019D5 | [2] | ROD | KOBJOINT, BALL |
| 51. | 2406T1231 | [1] | LINK | |
| 53. | ZW22X12000 | [2] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 54. | ZS12C08020 | [4] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm Superseded by part number: ZS18C08020 |
| 55. | 2416P4300 | [2] | BRACKET | |
| 56. | 2436P116 | [1] | CONTROL VALVE, REPRO | |
| 57. | 2436P117 | [1] | CONTROL VALVE, REPRO | |
| 58. | 2427R223 | [1] | MAT, FLOOR | |
| 60. | 2479T221 | [1] | HARNESS | |
| 61. | 24100J2458F2 | [1] | LABEL, NAME-PLATE | |
| 62. | 2418T6137 | [2] | PLATE | |
| 63. | ZS16C10016 | [6] | SCREW | KOBM10x1.50x16mm Superseded by part number: ZS18C10016 |
| 64. | B20P0005D65 | [1] | ROD | |
| 65. | B20P0005D56 | [1] | ROD | |
| 66. | 2420P1161D1 | [1] | ROD | |
| 67. | B20P0005060 | [1] | ROD | |
| 68. | 2420P1160D1 | [1] | ROD | |
| 69. | 2420P1159D1 | [1] | ROD | |
| 70. | 2420P1159D2 | [1] | ROD | |
| 71. | 2420P1160D2 | [1] | ROD | |
| 72. | 24100N1414F2 | [1] | LINK ASSY, CONSISTS OF REF. 72-1 TO 72-9 | |
| 72-1. | 2406P1636 | [1] | LINK | |
| 72-2. | 2406P1637 | [1] | LINK | |
| 72-3. | 2406P1638 | [1] | LINK | |
| 72-4. | 2406P1635 | [1] | LINK | |
| 72-6. | 2425Z394D17 | [8] | BUSHING | KOB |
| 72-7. | ZN11C08007 | [16] | NUT | KOBM08x1.25mm Superseded by part number: ZN16C08007 |
| 72-8. | ZM11C08020 | [16] | BOLT | KOBM08x1.25x20mm (Incls. Lockwasher) Superseded by part number: ZM12C08020 |
| 72-9. | 2416N1766 | [1] | BRACKET | |
| 73. | 24100P598F2 | [2] | BRACKET ASSY, CONSISTS OF REF. 73-1 TO 73-12 | |
| 73-1. | 2406P1634 | [1] | LINK | |
| 73-2. | 2416T5907 | [1] | BRACKET | |
| 73-3. | 2419T2256 | [1] | PIN | |
| 73-6. | ZS11C06045 | [1] | CAPSCREW | |
| 73-7. | ZN11C06005 | [1] | NUT | KOBNUT M06x1.0mm Superseded by part number: ZN18C06005 |
| 73-8. | ZW22X06000 | [1] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 73-9. | 4020T146D1 | [1] | SHIM | |
| 73-10. | 4020T146D2 | [1] | SHIM | |
| 73-11. | 4020T146D3 | [1] | SHIM | |
| 73-12. | 2405Z131D2 | [1] | BUSHING | |
| 74. | ZP45X12035 | [6] | PIN | KOB |
| 75. | 2419R9D4 | [6] | COTTER PIN | KOBSnap -- OD 12mm x 35.8mm Long |
