纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (23.611[003]) - CONTROL BLOCK MOUNTING PARTS (S/N 11701-12057) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
721 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NS | [1] | NOT SERVICED | BASCONTROL BLOCK SEE FIGURE 23.612/002 |
| 2. | 73170489 | [2] | HYD CONNECTOR | BERTUBE FITTING Superseded by part number: 2213963 |
| 3. | 73175628 | [1] | BRACKET | BER Superseded by part number: 1272577 |
| 10. | 73170296 | [13] | HYD CONNECTOR | BERSOCKET Superseded by part number: 73170297 |
| 12. | 73171890 | [4] | SOCKET | BER Superseded by part number: 1791011 |
| 14. | 73171891 | [3] | BOLT,Hex, M12 x 180, 8.8 | BERHEXAGON BOLT Superseded by part number: 336383 |
| 15. | 73170162 | [3] | NUT,M12, Cl 8 | BERHEXAGON NUT Superseded by part number: 9706685 |
| 16. | 73170715 | [3] | WASHER | NHDISK/WASHER Superseded by part number: 84089872 |
| 17. | 73171892 | [1] | SOCKET | BER Superseded by part number: 1636029 |
| 18. | 73170255 | [1] | LUBE NIPPLE | BERNIPPLE Superseded by part number: 1148460 |
| 19. | 73170051 | [1] | PLUG | BERSCREW PLUG Superseded by part number: 1350997 |
| 22. | 73175204 | [1] | HOSE | BER Superseded by part number: 1292304 |
| 23. | 73181288 | [1] | FLEXIBLE HOSE | BERHOSE Superseded by part number: 3003708 |
| 28. | 73170510 | [2] | HYD CONNECTOR | BERSOCKET Superseded by part number: 2247096 |
| 29. | 73170393 | [1] | HYD CONNECTOR | BERSOCKET Superseded by part number: 1636018 |
| 30. | 73178055 | [1] | REGULATOR | BER Superseded by part number: 73171895, 73171895, 73171896 |
| 32. | 73171895 | [1] | REGULATOR | BER Superseded by part number: 2459598 |
