纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (23.611[005]) - CONTROL BLOCK MOUNTING PARTS (S/N 12058-UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
697 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NS | [1] | NOT SERVICED | BASCONTROL BLOCK SEE FIGURE 23.612/002 |
| 2. | 73170489 | [2] | HYD CONNECTOR | BERTUBE FITTING Superseded by part number: 2213963 |
| 3. | 73175628 | [1] | BRACKET | BER Superseded by part number: 1272577 |
| 10. | 73170296 | [13] | HYD CONNECTOR | BERSOCKET Superseded by part number: 73170297 |
| 12. | 73171890 | [4] | SOCKET | BER Superseded by part number: 1791011 |
| 14. | 73186755 | [3] | BOLT,Hex, M12 x 180, 10.9 | BERHEXAGON BOLT Superseded by part number: 2980453 |
| 15. | 73170922 | [3] | LOCK NUT,M12 x 1.75, Cl 10 | BERHEXAGON NUT Superseded by part number: 412672 |
| 16. | 73188245 | [3] | WASHER | BERDISK/WASHER Superseded by part number: 1324019 |
| 17. | 73171892 | [1] | SOCKET | BER Superseded by part number: 1636029 |
| 18. | 73170255 | [1] | LUBE NIPPLE | BERNIPPLE Superseded by part number: 1148460 |
| 19. | 73170051 | [1] | PLUG | BERSCREW PLUG Superseded by part number: 1350997 |
| 22. | 73175204 | [1] | HOSE | BER Superseded by part number: 1292304 |
| 30. | 73178055 | [1] | REGULATOR | BER Superseded by part number: 73171895, 73171895, 73171896 |
| 32. | 73171895 | [1] | REGULATOR | BER Superseded by part number: 2459598 |
