神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (02-004) - INSTAL, CAB, (FOR EXPORT) P/N 24100J3166F16 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
870 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J3166F16 | [1] | INSTAL, CAB | INSTAL, CAB |
| 3. | ZM11C10020 | [4] | SCREW | KOBM10x1.50x20mm (Incls. Lockwasher) Superseded by part number: ZM12C10020 |
| 4. | 2416T6761D7 | [1] | SHEET | KOB |
| 5. | 2414R152 | [1] | INSULATION | INSULATION |
| 7. | 2414R143 | [1] | INSULATION, HEAT | INSULATION, HEAT |
| 8. | 2414R139 | [1] | FOAM INSULATION | KOB |
| 9. | 2414R137 | [1] | FOAM INSULATION | KOB |
| 10. | 2416T8662 | [1] | SHEET, RUBBER | SHEET, RUBBER |
| 11. | 2414R154 | [1] | INSULATION, HEAT | INSULATION, HEAT |
| 13. | ZW13H16000 | [4] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 16. | ZW13H12000 | [4] | WASHER | KOB |
| 31. | ZS18C16080 | [4] | SCREW,Hex, M16 x 80mm | KOBM16x2.0x80mm |
| 32. | ZS18C12025 | [3] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| 33. | ZS18C12060 | [1] | SCREW,Hex, M12 x 60mm | KOBM12x1.75x60mm |
| 40. | 24100U81F3 | [1] | SEAT ASSY | SEAT ASSY |
| 40-2. | 24100U81S2 | [1] | SUSPENSION | KOBSUSPENTION ASSY |
| 40-7. | 24100U81S7 | [1] | SEAT ASSY | SEAT ASSY |
| 49. | 2427U306D2 | [1] | MAT, FLOOR | MAT, FLOOR |
| 60. | 24100X1349F10 | [1] | CAB ASSY SEE FIG.02-009 | CAB ASSY SEE FIG.02-009 |
| 65. | 2414R232D1 | [1] | INSULATION, HEAT MACHINE SCREW | INSULATION, HEAT MACHINE SCREW |
| 67. | ZS31C04006 | [2] | SCREW,Phillips Drive, Pan HD, M4 x 6mm | KOBM04x0.7x06mm |
| 68. | 2418Z707 | [2] | WASHER | |
