纽荷兰零件查询(EC350) - CRAWLER EXCAVATOR (2/00-) (24.022[001]) - BOOM CYLINDERS (S/N 735003-UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
869 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 71470386 | [1] | HYDRAULIC CYLINDER | TORCYLINDER |
| 10. | 71470167 | [1] | ROD,105mm OD x 1995mm L | TORPISTON ROD |
| 11. | 71464070 | [2] | BUSHING,110mm ID x 125mm OD x 45mm L | TOR |
| 20. | 71470907 | [1] | CYLINDER | TORLINER |
| 30. | 71470391 | [1] | SEAL | TORPACKET SEAL |
| 40. | 71470916 | [1] | CYLINDER HEAD | TORGUIDE |
| 44. | 71448381 | [1] | KIT | TORCLEVIS PIN |
| 50. | 71470408 | [1] | SEALING RING | TORGASKET |
| 60. | 71470390 | [1] | SEAL | TOR |
| 70. | 71470156 | [12] | HEX SOC SCREW | TOR |
| 80. | 71470915 | [1] | BUSHING | TOR |
| 90. | 71470402 | [1] | SEAL KIT | TORPACKET SEAL |
| 110. | 71470914 | [1] | PISTON | TOR |
| 111. | 71469238 | [1] | NUT | TOR |
| 112. | 71448003 | [1] | WASHER | TORSPACER SLEEVE |
| 113. | 71445657 | [1] | DOWEL,M14 x 2 x 14mm | TORSTUD |
| 114. | 71445658 | [1] | BALL | TOR Superseded by part number: 20063470 |
| 115. | 13407211 | [1] | LUBE NIPPLE,M10 x 1 | TTFNIPPLE, LUBE, M10 x 1 Superseded by part number: 84351730 |
