神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (02-012) - GUARD ASSY, P/N 24100N2804F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
536 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N2804F1 | [1] | GUARD ASSY | |
| 1. | 2414N1883 | [1] | GUARD, HEAD | |
| 2. | 2427T837D3 | [1] | STAY | |
| 3. | 2427T837D2 | [1] | STAY | |
| 4. | 2427T837D1 | [2] | STAY | |
| 5. | 2432T1778 | [1] | LABEL | KOBPLATE, CAUTION |
| 6. | 2416T10854 | [5] | PLATE | |
| 7. | ZS13C14085 | [15] | SCREW | KOBM14x2.0x75mm Superseded by part number: ZS18C14085 |
| 8. | ZS13C16045 | [8] | SCREW | KOBScrew -- M16x2.0x45mm |
| 9. | 2420T4341 | [4] | RIVET | |
| 10. | ZW22X14000 | [15] | LOCK WASHER | KOBID 14 x OD 24.5 x Th 3.5mm Superseded by part number: ZW26X14000 |
| 11. | ZW22X16000 | [8] | WASHER, LOCK | KOBID 16 x OD 28.0 x Th 4.0mm |
| 12. | ZN12C16013 | [8] | NUT | KOBM16x2.0mm |
