神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (02-013) - GUARD ASSY, (FOR EXPORT0 P/N 24100J4702F3 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
245 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J4702F3 | [1] | GUARD ASSY, Serial Range: LE3401-LE5518 | |
| . . | 24100J4702F6 | [1] | GUARD ASSY, Start Serial: LE5519 | |
| 10. | 2432T1439 | [1] | CLAMP | KOB |
| 11. | 2420T3968 | [12] | BOLT | KOB |
| 12. | R16T0137D3 | [12] | WASHER | KOBCone Disk Spring -- ID 10.2 x OD 20 x Th 0.8mm |
| 14. | 2418T5375C2 | [12] | WASHER | |
| 15. | 2414P2877 | [1] | GUARD | GUARD |
| 19. | 2414P2922 | [1] | GUARD | GUARD |
| 20. | 2414P2925 | [1] | GUARD | GUARD |
| 22. | 2414P2921 | [1] | GUARD | GUARD |
| 24. | 2414P2931 | [1] | GUARD | |
| 25. | 2414P2932 | [1] | GUARD, Serial Range: LE3401-LE5518 | GUARD, Serial Range: LE3401-LE5518 |
| 26. | 2414P2933 | [1] | GUARD | |
| 27. | 2414P2930 | [1] | GUARD | |
| 28. | 2427J1266 | [1] | REWORK, CAB | |
| 34. | 2414P3911 | [1] | GUARD, Start Serial: LE5519 | |
