| 1. |
84074691
|
[1] |
SHAFT
|
ZED
|
| 1. |
84074553
|
[1] |
SHAFT
|
ZED
, Serial Range: -C144
|
| 1. |
47939737
|
[1] |
DRIVE SHAFT
|
ZED
, Start Serial: D145
|
| 2. |
84053926
|
[1] |
HYD CONNECTOR
|
ZED
|
| 3. |
552118
|
[1] |
SEALING RING
|
ZED
Superseded by part number: 80552118
|
| 4. |
84078076
|
[1] |
BEARING HOUSING,75 mm ID x 130 mm OD x 64 mm
|
ZED
|
| 5. |
84074234
|
[1] |
BEARING, ROLLER, CYL,60mm ID x 110mm OD x 28mm W
|
ZED
Superseded by part number: 428162
|
| 6. |
84074232
|
[1] |
SEAL,90mm ID x 110mm OD x 8mm Thk
|
ZED
|
| 7. |
84074231
|
[2] |
ADJUSTING PLATE
|
ZED
|
| 8. |
84078069
|
[1] |
HUB
|
ZED
|
| 9. |
84074362
|
[1] |
DRIVEN SPROCKET
|
ZED
, Serial Range: -C144 Superseded by part number: 47860193
|
| 9. |
47860193
|
[1] |
SPROCKET
|
ZED
, Start Serial: D145
|
| 10. |
84074230
|
[1] |
BUSHING,60mm ID x 65mm OD x 60mm L
|
ZED
|
| 11. |
84037875
|
[1] |
LINK,Chain
|
ZED
, Serial Range: -C136
|
| 11. |
47852999
|
[1] |
LINK
|
ZED
, Start Serial: D137
|
| 12. |
556831
|
[2] |
SHIM,1mm Thk
|
PA
|
| 13. |
556885
|
[2] |
SHIM,0.3mm Thk
|
PA
|
| 14. |
853175
|
[2] |
FLANGE
|
ZED
Superseded by part number: 76450
|
| 15. |
9839285
|
[1] |
BALL BEARING,55mm ID x 100mm OD x 24mm W
|
ZED
|
| 16. |
84074522
|
[1] |
COVER PLATE
|
ZED
|
| 17. |
84512427
|
[1] |
PROFILE
|
ZED
|
| 17. |
48037223
|
[1] |
PROFILE
|
ZED
, Start Serial: D160
|
| 18. |
84058691
|
[1] |
CHAIN,120HV, 82 Links x 38.1mm = 3124.2mm
|
ZED
Incl 11, Serial Range: -C136
|
| 18. |
47663745
|
[1] |
CHAIN
|
ZED
Incl 11, Start Serial: D137
|
| 19. |
87656273
|
[1] |
GUARD
|
ZED
|
| 20. |
84801355
|
[1] |
PLATE
|
ZED
|
| 21. |
140046
|
[7] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 22. |
300388
|
[3] |
BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8
|
NH
, Serial Range: -C106
|
| 22. |
9706687
|
[3] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
, Start Serial: D107
|
| 23. |
301652
|
[1] |
SNAP RING,M110 x 4mm, Internal
|
ZED
|
| 24. |
394630
|
[12] |
WASHER,13mm ID x 28mm OD x 4mm Thk
|
NH
Superseded by part number: 86625256
|
| 25. |
412605
|
[12] |
BOLT,Hex, M12 x 1.75 x 90mm, Cl 10.9
|
WIN
|
| 26. |
370027
|
[1] |
SNAP RING,M60, Ext
|
ZED
|
| 27. |
120044
|
[4] |
CARRIAGE BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 28. |
9706685
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 29. |
327911
|
[1] |
CIRCLIP,55mm ID
|
BHB
|
| 30. |
43168
|
[6] |
BOLT,Hex, M16 x 40mm, Cl 8.8
|
NH
Superseded by part number: 86509867
|
| 31. |
394631
|
[12] |
WASHER,17mm ID x 34mm OD x 4mm Thk
|
NH
|
| 32. |
100020
|
[6] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 33. |
86508570
|
[1] |
BOLT,Hex, M6 x 80mm OAL, Cl 8.8
|
NH
|
| 34. |
353308
|
[1] |
NUT,M6 x 1.0, Cl 8
|
NH
|
| 35. |
321204
|
[1] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 36. |
14442131
|
[2] |
SCREW,Flat Csk Hd, M8 x 1.25 x 25mm, Cl 10.9
|
FOR
Superseded by part number: 14442134
|
| 37. |
378243
|
[2] |
WASHER,8.4mm ID x 21mm OD x 1.6mm Thk
|
NH
Superseded by part number: 63707, 63707, 86625263
|
| 38. |
412250
|
[2] |
NUT,M8 x 1.25, Cl 8
|
WIN
Superseded by part number: 86528579
|
| 39. |
86507486
|
[3] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 40. |
322358
|
[3] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 41. |
9706690
|
[3] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
