| 1. |
84417745
|
[1] |
FEEDER
|
ZED
, Serial Range: -C129
|
| 1. |
47742067
|
[1] |
FEEDER
|
ZED
, Serial Range: -F130150 Superseded by part number: 47925151
|
| 1. |
47925151
|
[1] |
FEEDER
|
ZED
, Start Serial: D151
|
| 1. |
84410006
|
[1] |
FEEDER
|
ZED
, Serial Range: -C129
|
| 1. |
47742071
|
[1] |
FEEDER
|
ZED
, Serial Range: -F130150 Superseded by part number: 47925168
|
| 1. |
47925168
|
[1] |
FEEDER
|
ZED
, Start Serial: D151
|
| 2. |
84042607
|
[1] |
COVER PLATE
|
ZED
LH, Serial Range: -C150
|
| 2. |
47824940
|
[1] |
REINFORCEMENT
|
ZED
LH, Start Serial: D151
|
| 3. |
84042608
|
[1] |
COVER PLATE
|
ZED
RH, Serial Range: -C150
|
| 3. |
47824921
|
[1] |
REINFORCEMENT
|
ZED
RH, Start Serial: D151
|
| 4. |
84269032
|
[1] |
SHIELD
|
ZED
|
| 5. |
47375039
|
[1] |
PLATE
|
ZED
|
| 6. |
543043
|
[4] |
WASHER,13mm ID x 35mm OD x 2.5mm Thk
|
NH
|
| 7. |
140046
|
[6] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 8. |
300388
|
[4] |
BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8
|
NH
|
| 9. |
374895
|
[4] |
CARRIAGE BOLT,M12 x 1.75 x 25mm, Cl 8.8
|
NH
|
| 10. |
9706685
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 11. |
378246
|
[8] |
WASHER,17mm ID x 34mm OD x 3mm Thk
|
ZED
|
| 12. |
385922
|
[8] |
BOLT,Hex, M16 x 2 x 45mm, Cl 8.8
|
NH
|
| 13. |
140048
|
[16] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 14. |
100020
|
[8] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 15. |
86508583
|
[4] |
BOLT,Hex, M16 x 35mm, Cl 8.8, Full Thd
|
NH
Superseded by part number: 86529976
|
| 16. |
308761
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 17. |
9706690
|
[10] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 18. |
140045
|
[6] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 19. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 20. |
100016
|
[4] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 21. |
86624184
|
[8] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
FOR
|
| 22. |
338949
|
[4] |
CARRIAGE BOLT,M10 x 1.5 x 25mm, Cl 8.8
|
NH
|
| 23. |
394631
|
[16] |
WASHER,17mm ID x 34mm OD x 4mm Thk
|
NH
|
| 24. |
120090
|
[4] |
BOLT,Hex, M16 x 50mm, Cl 8.8
|
NH
|
| 25. |
86000441
|
[8] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 26. |
120038
|
[2] |
CARRIAGE BOLT,Rnd Head, M8 x 1.25 x 30mm, Cl 8.8, Full Thd
|
NH
Superseded by part number: 811-8030
|
