| 1. |
84607490
|
[3] |
PLATE
|
ZED
|
| 2. |
43138
|
[1] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8
|
NH
|
| 3. |
84607491
|
[2] |
PLATE
|
ZED
|
| 4. |
84038526
|
[2] |
BEARING CARRIER,25mm ID
|
ZED
|
| 5. |
84389943
|
[1] |
SHAFT
|
ZED
|
| 5. |
84389064
|
[1] |
SHAFT
|
ZED
, Serial Range: -C129
|
| 5. |
47738862
|
[1] |
SHAFT
|
ZED
, Start Serial: D130
|
| 6. |
84269802
|
[1] |
PLATE
|
ZED
, Serial Range: -C150 Superseded by part number: 47928744
|
| 6. |
47928744
|
[1] |
PLATE
|
ZED
, Start Serial: D151
|
| 6. |
84269799
|
[1] |
PLATE
|
ZED
, Serial Range: -C150
|
| 6. |
47810991
|
[1] |
PLATE
|
ZED
, Start Serial: D151
|
| 7. |
87617285
|
[2] |
GUIDE
|
ZED
|
| 8. |
87617287
|
[3] |
GUIDE
|
ZED
|
| 9. |
84210682
|
[1] |
PLATE
|
ZED
|
| 10. |
84042706
|
[1] |
COVER PLATE
|
ZED
|
| 11. |
84210681
|
[1] |
PLATE
|
ZED
|
| 12. |
84043925
|
[1] |
ROD
|
ZED
|
| 13. |
84004713
|
[1] |
BUSHING,10.5mm ID x 25mm OD x 18mm L
|
ZED
, Serial Range: -C129
|
| 14. |
43139
|
[8] |
BOLT,M10 x 1.5 x 25mm, Cl 8.8
|
NH
Superseded by part number: 11106231
|
| 15. |
412183
|
[1] |
CARRIAGE BOLT,Short Sq Nk, M10 x 35mm, Cl 8.8
|
DUB
, Serial Range: -C129 Superseded by part number: 9833222
|
| 16. |
854963
|
[1] |
SPACER,10.5mm ID x 16mm OD x 8.5mm L
|
NH
|
| 17. |
333115
|
[2] |
BOLT
|
ZED
|
| 18. |
334966
|
[4] |
CARRIAGE BOLT,Sht Nk, M12 x 1.75 x 45mm, Cl 8.8, Full Thd
|
PA
|
| 19. |
86511324
|
[4] |
WASHER,13mm ID x 24mm OD x 2.5mm Thk
|
NH
Superseded by part number: 87364
|
| 20. |
100020
|
[4] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 21. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 22. |
9706704
|
[1] |
BOLT,Hex, M10 x 1.5 x 41.58mm, Cl 8.8
|
NH
|
| 23. |
140042
|
[1] |
WASHER,11mm ID x 34mm OD x 3mm Thk
|
GI
|
| 24. |
100037
|
[1] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 25. |
140045
|
[1] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 26. |
86512446
|
[1] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 27. |
9706685
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 28. |
333969
|
[2] |
SPRING
|
ZED
Superseded by part number: 80918027
|
| 29. |
84069248
|
[1] |
RIVET,Pop, 4.8mm OD x 20.7mm L
|
ZED
|
| 30. |
84007183
|
[4] |
WASHER,16.5mm ID x 58mm OD x 6mm Thk
|
ZED
|
| 31. |
120093
|
[2] |
BOLT,M16 x 2.0 x 90.18mm, Cl 8.8
|
NH
|
| 32. |
9837933
|
[2] |
SPACER,17mm ID x 25.4mm OD x 12.5mm L
|
ZED
|
| 33. |
86000441
|
[4] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 34. |
120092
|
[1] |
BOLT,M16 x 70mm, Cl 8.8
|
NH
|
| 35. |
376291
|
[1] |
SPACER,16.5mm ID x 25mm OD x 11mm L
|
ZED
|
| 36. |
140041
|
[4] |
WASHER,M8 x 28mm OD x 3mm Thk
|
ZED
Superseded by part number: 9826296
|
| 37. |
378246
|
[2] |
WASHER,17mm ID x 34mm OD x 3mm Thk
|
ZED
|
| 38. |
323866
|
[1] |
BOLT,Hex, M16 x 2.0 x 60mm, Cl 8.8
|
NH
Superseded by part number: 120091
|
| 39. |
84424658
|
[1] |
PLATE
|
ZED
, Serial Range: -C150
|
| 39. |
47947889
|
[1] |
PLATE
|
ZED
, Serial Range: -F151159
|
| 39. |
48057280
|
[1] |
PLATE
|
ZED
, Start Serial: D160
|
| 39. |
84388901
|
[1] |
PLATE
|
ZED
, Serial Range: -C150
|
| 39. |
47947885
|
[1] |
PLATE
|
ZED
, Serial Range: -F151159
|
| 39. |
48054878
|
[1] |
PLATE
|
ZED
, Start Serial: D160
|
| 40. |
308761
|
[8] |
CARRIAGE BOLT,M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 41. |
9706690
|
[12] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 42. |
84607487
|
[2] |
STIFFENER
|
ZED
|
| 43. |
84607485
|
[3] |
PLATE
|
ZED
|
| 44. |
322358
|
[12] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 45. |
43128
|
[4] |
BOLT,M8 x 1.25 x 30mm, Cl 8.8
|
NH
|
| 46. |
84817509
|
[3] |
BRACKET
|
ZED
, Serial Range: -C129
|
| 46. |
47679234
|
[3] |
SPACER
|
ZED
, Start Serial: D130
|
| 47. |
84817511
|
[2] |
BRACKET
|
ZED
, Serial Range: -C129
|
| 47. |
47679215
|
[2] |
SPACER
|
ZED
, Start Serial: D130
|
| 48. |
338949
|
[1] |
CARRIAGE BOLT,M10 x 1.5 x 25mm, Cl 8.8
|
NH
, Serial Range: -C129
|
