| 1. |
84335471
|
[2] |
PIN,25mm OD x 70mm L
|
ZED
|
| 2. |
47359452
|
[1] |
FRAME
|
ZED
, Serial Range: -C129
|
| 2. |
47798255
|
[1] |
FRAME
|
ZED
, Start Serial: D130
|
| 2. |
47359467
|
[1] |
FRAME
|
ZED
, Serial Range: -C129 Superseded by part number: 47798259
|
| 2. |
47798259
|
[1] |
FRAME
|
ZED
, Start Serial: D130
|
| 3. |
84345946
|
[1] |
SHAFT
|
ZED
|
| 3. |
84345949
|
[1] |
SHAFT
|
ZED
|
| 4. |
84039445
|
[1] |
STOP
|
ZED
|
| 5. |
84042703
|
[1] |
HOOK
|
ZED
|
| 6. |
84042262
|
[1] |
COVER PLATE
|
ZED
|
| 7. |
9839186
|
[1] |
KNOB
|
ZED
|
| 8. |
370002
|
[2] |
CIRCLIP,M25, External
|
NH
|
| 9. |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
, Serial Range: -C129
|
| 9. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
, Start Serial: D130
|
| 10. |
86977726
|
[2] |
BOLT,Hex, M6 x 12mm, Cl 8.8
|
ZED
, Serial Range: -C129
|
| 10. |
120103
|
[2] |
BOLT,M8 x 1.25 x 16mm, Cl 8.8
|
NH
, Start Serial: D130 Superseded by part number: 16043224
|
| 11. |
140103
|
[2] |
WASHER,26mm ID x 38mm OD x 1mm Thk
|
ZED
Superseded by part number: 140229
|
| 12. |
330413
|
[1] |
BANJO BOLT
|
ZED
|
| 13. |
9706685
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 14. |
334682
|
[1] |
CARRIAGE BOLT,Sht Nk, M12 x 1.75 x 50mm, Cl 8.8, Full Thd
|
ZED
|
| 15. |
378245
|
[3] |
WASHER,13mm ID x 28.5mm OD x 2.7mm Thk
|
NH
|
| 16. |
140046
|
[2] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 17. |
328754
|
[1] |
CARRIAGE BOLT,M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 18. |
84021756
|
[1] |
BANJO BOLT
|
ZED
|
| 19. |
325829
|
[1] |
BOLT,Hex, M10 x 1.5 x 45mm, Cl 8.8
|
NH
Superseded by part number: 56614
|
| 20. |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 21. |
355988
|
[2] |
SPRING
|
ZED
|
| 22. |
14607370
|
[1] |
ROLL PIN,M8 x 45, Slotted
|
MKT
|
| 23. |
26558
|
[2] |
WASHER,28.5mm ID x 45.2mm OD x 1.7mm Thk
|
NH
|
| 24. |
84361665
|
[2] |
SPACER,28.5mm ID x 60mm OD x 24mm L
|
ZED
|
| 25. |
86977792
|
[1] |
SLOTTED PIN,5mm OD x 40mm L, Slotted
|
ZED
|
