纽荷兰零件查询(CL145) - CRAWLER LOADER (2/01-) (1.200[07]) - TORQUE CONVERTER - COMPONENTS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
403 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 9915508 | [1] | IMPELLER | LEC |
| 2. | 73027717 | [1] | IMPELLER | LEC |
| 3. | 73035008 | [1] | ALTERNATOR STATOR | CMI |
| 4. | 28995890 | [1] | BALL BEARING | LEC Superseded by part number: 5168238 |
| 5. | 9921467 | [6] | SCREW | LEC |
| 6. | 73035093 | [1] | PLATE | LEC |
| 7. | 73039119 | [2] | SCREW | LEC Superseded by part number: 70922851 |
| 8. | 76004308 | [1] | SLEEVE | LEC |
| 9. | 9915537 | [1] | SHAFT | LEC |
| 10. | 70922405 | [6] | SCREW | LEC |
| 11. | 73035018 | [1] | RING | LEC Superseded by part number: A22889 |
| 12. | 73035014 | [2] | PLATE | LEC |
| 13. | 70921459 | [4] | LOCK PIN,9.53mm OD x 15.88mm L, Slotted | LEC |
| 14. | 70921768 | [4] | LOCK PIN,5.56mm OD x 15.88mm L, Slotted | LEC |
| 15. | 9921468 | [8] | SCREW | LEC |
| 16. | 73027731 | [2] | SPACER | LEC |
| 17. | 9921466 | [1] | O-RING | LEC |
| 18. | 9921465 | [1] | GEAR | LEC |
| 19. | 26794630 | [1] | BALL BEARING,95mm ID x 145mm OD x 16mm W | LEC95 x 145 x 16 |
| 20. | 9915528 | [1] | RING | LEC |
| 21. | 20065730 | [1] | BALL BEARING,55mm ID x 120mm OD x 29mm W | TTF55 x 120 x 29 Superseded by part number: 87562151 |
| 22. | 70628519 | [1] | SNAP RING,2.77mm Thk, Ext | LEC |
| 23. | 73037629 | [1] | PISTON RING | LEC |
| 24. | 79013445 | [1] | BUSHING | LEC |
| 25. | 70923276 | [2] | SCREW,Hex, 3/8" - 24 x 1", Gr 8 | LEC |
| 26. | 9915534 | [1] | DISC | LEC |
| 27. | 70628362 | [1] | O-RING,0.21" Thk x 2.1" ID, -330, Cl 5, 75 Duro | LEC Superseded by part number: 235760 |
| 28. | 9921464 | [1] | CASE | LEC- ASSY |
| 29. | 70917673 | [2] | PLUG | LEC Superseded by part number: 70901652 |
| 30. | 9926238 | [1] | IMPELLER | LEC |
| 31. | 76004309 | [24] | BOLT | LEC |
