纽荷兰零件查询(CL145) - CRAWLER LOADER (2/01-) (1.200[08]) - UNIT TORQUE CONVERTER - VALVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
664 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 597092 | [1] | RING NUT | LEC |
| 2. | 79043953 | [1] | SEAT/SLOT | LEC |
| 3. | 79043954 | [1] | PLUNGER | LEC |
| 4. | 10730321 | [1] | WASHER,8.15mm ID x 17mm OD x 2mm Thk | JES Superseded by part number: 16665514 |
| 5. | 8280351 | [1] | SPRING | LEC |
| 6. | 79101856 | [1] | GUIDE | LEC |
| 7. | 593198 | [1] | SPRING | LEC |
| 8. | 581593 | [1] | LOCK NUT | LEC |
| 9. | 79101855 | [1] | SCREW,M8 x 100mm, Cl 10.9 | LEC |
| 10. | 13550201 | [1] | WASHER,6.15mm ID x 13mm OD x 1mm Thk | LEC6,15X13 Superseded by part number: 17094724 |
| 11. | 79101854 | [1] | PRESSURE CONTROL VALVE | LEC |
| 12. | 79068722 | [1] | PLUG | LEC |
| 13. | 14325301 | [1] | PLUG | LEC22X1,5X13 Superseded by part number: 16997711 |
| 14. | 14457681 | [1] | O-RING,0.103" Thk x 0.862" ID, -118, Cl 7, 75 Duro | TTF |
| 15. | 10333910 | [1] | PIN | LEC4X25 |
| 16. | 71305686 | [1] | SEALING WASHER | LEC Superseded by part number: 8289371 |
| 17. | 8295459 | [1] | SEAL | LEC |
