| . . | 24100J4068F2 | [1] | CONTROL ASSY, Serial Range: LE3401-LE4161 | |
| . . | 24100J4068F4 | [1] | CONTROL ASSY, Start Serial: LE4162 | |
| 3. | 2420Z681 | [6] | ROD | KOB |
| 4. | 2420T4065 | [6] | STUD | KOB |
| 5. | ZN16C08007 | [10] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08007 |
| 10. | 2406T1385 | [2] | YOKE | KOB, Serial Range: LE3401-LE4102 Superseded by part number: 2406T2278 |
| 10. | 2406T1672 | [2] | YOKE | KOB, Start Serial: LE4103 Superseded by part number: 2406T2278 |
| 12. | B16T0569 | [1] | PLATE, Serial Range: LE3401-LE3496 | |
| 13. | B16T0568 | [1] | PLATE, Serial Range: LE3401-LE3496 | |
| 14. | 2406T1188C2 | [4] | EYE BOLT | EYE BOLT |
| 15. | 2425R145D1 | [4] | BLOCK/ BEARING | |
| 16. | ZM11C08020 | [8] | BOLT | KOBM08x1.25x20mm (Incls. Lockwasher) Superseded by part number: ZM12C08020 |
| 18. | ZW16X08000 | [8] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 19. | ZP45X12030 | [10] | PIN | KOBLE3401 to LE4 102 |
| 19. | 2419T3642D1 | [10] | PIN | KOB, Serial Range: LE4103-LE5080 Superseded by part number: 2419T3784D1 |
| 20. | ZW16X12000 | [10] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 21. | 241989D4 | [10] | PIN,SHAPPER | |
| 24. | 2406T1187D1 | [8] | LINK, Serial Range: LE3401-LE3496 | |
| 25. | 24100N1839F2 | [1] | LEVER ASSY, CONTROL | |
| 25-3. | 4019T12 | [1] | PIN | KOB |
| 25-4. | 4016P16 | [1] | BRACKET | KOB |
| 25-5. | 4018T20 | [2] | SPACER | KOB |
| 25-6. | 4025Z8 | [4] | NEEDLE BEARING | KOB |
| 25-7. | 4045Z8 | [4] | OIL SEAL | KOB |
| 25-8. | 6Z1 | [2] | LEVER | KOB |
| 25-9. | 3611V012 | [1] | WASHER | KOB |
| 25-10. | ZP15D05065 | [1] | COTTER PIN | KOB |
| 25-11. | 2406P2339 | [1] | LEVER, CONTROL | |
| 25-12. | 2406P2340 | [1] | LEVER, CONTROL | |
| 27. | ZM11C10030 | [12] | SCREW | KOBM10x1.50x30mm (Incls. Lockwasher), Serial Range: LE3401-LE4161 |
| 29. | 2419P1422 | [1] | PIN, Serial Range: LE3401-LE4161 | PIN, Serial Range: LE3401-LE4161 |
| 30. | 2432Z290 | [2] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 32. | 2406P2065D2 | [1] | LEVER | KOB Superseded by part number: 2406P2065D5 |
| 33. | 2406P2065D1 | [1] | BALL, LEVER | BALL, LEVER |
| 34. | ZN16C12007 | [4] | NUT, Serial Range: LE3401-LE3562 | NUT, Serial Range: LE3401-LE3562 |
| 35. | 2406T1645 | [2] | LEVER, Serial Range: LE3401-LE3562 | |
| 36. | 2414R228 | [2] | BOOT | KOB |
| 37. | 2406R219D1 | [2] | FLEXIBLE CONTROL | KOB, Serial Range: LE3401-LE4161 |
| 38. | 2406U142F1 | [2] | CABLE ASSY, CONTROL, Serial Range: LE3401-LE4022 | |
| 38-1. | 2406U143F1 | [1] | DEVICE, CONTROL | |
| 38-1A. | 2406U143S1 | [1] | SHAFT | |
| 38-1B. | 2406U143S2 | [5] | CAPSCREW | |
| 38-1C. | 2406U143S3 | [5] | LOCK WASHER | |
| 38-1E. | 2406U143S5 | [1] | CLIP | |
| 38-1F. | 2406U143S6 | [1] | RUSHING | |
| 38-1H. | 2406U143S8 | [1] | BEARING | |
| 38-1I. | 2406U143S9 | [1] | BUSHING | |
| 38-1L. | 2406U143S12 | [1] | LEVER | |
| 38-1M. | 2406U143S13 | [1] | CLIP | |
| 38-10. | 2406U143S15 | [2] | BALL JOINT | BALL JOINT |
| 38-1P. | 2406U143S16 | [1] | COLLAR | |
| 38-1C. | 2406U143S17 | [1] | NUT | |
| 38-1R. | 2406U143S18 | [1] | LOCK WASHER | |
| 38-2. | 2406R203 | [2] | CABLE | KOBCABLE, CONTROL Superseded by part number: 2406U142S19 |
| 39. | 2416T9916 | [2] | STAND, CONTROL | |
| 40. | 2406P1596D3 | [1] | LINK | |
| 41. | 2406P1596D4 | [1] | LINK | |
| 42. | 2416T9924 | [2] | BRACKET | |
| 43. | ZS13C12028 | [4] | CAPSCREW | |
| 44. | ZN12C12010 | [6] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 45. | ZW22X12000 | [4] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 46. | ZS13C06010 | [8] | SCREW | KOBM06x1.0x10mm Superseded by part number: ZS18C06010 |
| 47. | ZW22X06000 | [8] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 48. | 2406T1643 | [1] | PLATE, Start Serial: LE3497 | PLATE, Start Serial: LE3497 |
| 49. | 2406T1644 | [1] | PLATE, Start Serial: LE3497 | PLATE, Start Serial: LE3497 |
| 50. | 2406T1650D1 | [8] | LINK, Start Serial: LE3497 | LINK, Start Serial: LE3497 |
| 51. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm, Start Serial: LE3497 |
| 52. | ZN16C12010 | [4] | NUT | KOB, Serial Range: LE3563-LE4161 Superseded by part number: ZN18C12010 |
| 53. | 2406T1656 | [2] | LEVER, Serial Range: LE3563-LE4161 | |
| 55. | 2406U142F2 | [2] | CAPLE ASSY, CONTROL, Start Serial: LE4023 | |
| 55-1. | 2406U143F2 | [1] | DEVICE, CONTROL | |
| 55-1A. | 2406U143S1 | [1] | SHAFT | |
| 55-1B. | 2406U143S2 | [5] | CAPSCREW | |
| 55-1C. | 2406U143S3 | [5] | LOCK WASHER | |
| 55-1E. | 2406U143S5 | [1] | CLIP | |
| 55-1F. | 2406U143S6 | [1] | BUSHING | |
| 55-1H. | 2406U143S8 | [1] | BEARING | |
| 55-11. | 2406U143S9 | [1] | BUSHING | |
| 55-1L. | 2406U143S12 | [1] | LEVER | |
| 55-1M. | 2406U143S13 | [1] | CLIP | |
| 55-10. | 2406U143S15 | [1] | BALL JOINT | BALL JOINT |
| 55-1P. | 2406U143S16 | [1] | COLLAR | |
| 55-10. | 2406U143S17 | [1] | NUT | |
| 55-1R. | 2406U143S18 | [1] | LOCK WASHER | |
| 55-1T. | 2406U143S20 | [1] | BALL & BUSHING | |
| 55-2. | 2406R203 | [2] | CABLE | KOBCABLE, CONTROL Superseded by part number: 2406U142S19 |
| 56. | 2419P1609 | [1] | PIN, Start Serial: LE4162 | |
| 5R. | 2406R203D4 | [2] | CABLE | KOB, Start Serial: LE4162 |
| 59. | 2406T1692 | [2] | LEVER LE4162 to | |
| 61. | ZM11C10025 | [8] | BOLT | KOBM10x1.50x25mm (Incls. Lockwasher), Start Serial: LE4162 Superseded by part number: ZM12C10025 |
| 63. | 2419T3784D1 | [10] | PIN | KOB19, Start Serial: LE5081 |
