神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (03-002) - CONTROL ASSY (FOR EXPORT) P/N 24100J4068F3 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
281 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J4068F3 | [1] | CONTROL ASSY | |
| 3. | NSS | [6] | NOT SOLD SEPARAT | CONROD-END |
| 4. | NSS | [6] | NOT SOLD SEPARAT | CONSTUD |
| 5. | NSS | [10] | NOT SOLD SEPARAT | CONNUT |
| 10. | NSS | [2] | NOT SOLD SEPARAT | CONYOKE, Serial Range: LE3401-LE4102 |
| 14. | NSS | [4] | NOT SOLD SEPARAT | CONYOKE |
| 15. | NSS | [4] | NOT SOLD SEPARAT | CONBLOCK,BEARING |
| 16. | NSS | [8] | NOT SOLD SEPARAT | CONSEMS-BOLT |
| 18. | NSS | [8] | NOT SOLD SEPARAT | CONWASHER |
| 19. | NSS | [10] | NOT SOLD SEPARAT | CONPIN, Serial Range: LE3401-LE4102 |
| 19. | 2419T3642D1 | [10] | PIN | KOB, Start Serial: LE4103 Superseded by part number: 2419T3784D1 |
| 20. | NSS | [10] | NOT SOLD SEPARAT | CONWASHER |
| 21. | NSS | [10] | NOT SOLD SEPARAT | CONPIN, SNAPPER |
| 27. | NSS | [12] | NOT SOLD SEPARAT | CONSEMS-BOLT |
| 29. | NSS | [1] | NOT SOLD SEPARAT | CONPIN |
| 30. | NSS | [2] | NOT SOLD SEPARAT | CONCLIP |
| 32. | NSS | [1] | NOT SOLD SEPARAT | CONGRIP |
| 33. | NSS | [1] | NOT SOLD SEPARAT | CONGRIP |
| 36. | NSS | [2] | NOT SOLD SEPARAT | CONBOOT |
| 37. | NSS | [2] | NOT SOLD SEPARAT | CONCABLE,CONTROL |
| 38. | NSS | [2] | NOT SOLD SEPARAT | CONCABLE ASSY, CONTROL, Serial Range: LE3401-LE4022 |
| 38-1. | NSS | [1] | NOT SOLD SEPARAT | CONDEVICE, CONTROL |
| 38-1A. | NSS | [1] | NOT SOLD SEPARAT | CONSHAFT |
| 38-1B. | NSS | [5] | NOT SOLD SEPARAT | CONCAPSCREW |
| 38-1C. | NSS | [5] | NOT SOLD SEPARAT | CONLOCK WASHER |
| 38-1E. | NSS | [1] | NOT SOLD SEPARAT | CONCLIP |
| 38-1F. | NSS | [1] | NOT SOLD SEPARAT | CONBUSHING |
| 38-1H. | NSS | [1] | NOT SOLD SEPARAT | CONBEARING |
| 38-1I. | NSS | [1] | NOT SOLD SEPARAT | CONBUSHING |
| 38-1L. | NSS | [1] | NOT SOLD SEPARAT | CONLEVER |
| 38-1M. | NSS | [1] | NOT SOLD SEPARAT | CONCLIP |
| 38-1O. | NSS | [2] | NOT SOLD SEPARAT | CONBALL & BEARING |
| 38-1P. | NSS | [1] | NOT SOLD SEPARAT | CONCOLLAR |
| 38-1Q. | NSS | [1] | NOT SOLD SEPARAT | CONNUT |
| 38-1R. | NSS | [1] | NOT SOLD SEPARAT | CONLOCK WASHER |
| 38-2. | NSS | [2] | NOT SOLD SEPARAT | CONCABLE, CONTROL |
| 39. | NSS | [2] | NOT SOLD SEPARAT | CONSTAND, CONTROL |
| 40. | NSS | [1] | NOT SOLD SEPARAT | CONLINK |
| 41. | NSS | [1] | NOT SOLD SEPARAT | CONLINK |
| 42. | NSS | [2] | NOT SOLD SEPARAT | CONBRACKET |
| 43. | NSS | [4] | NOT SOLD SEPARAT | CONCAPSCREW |
| 44. | NSS | [6] | NOT SOLD SEPARAT | CONNUT |
| 45. | NSS | [4] | NOT SOLD SEPARAT | CONLOCK WASHER |
| 46. | NSS | [8] | NOT SOLD SEPARAT | CONCAPSCREW |
| 47. | NSS | [8] | NOT SOLD SEPARAT | CONLOCK WASHER |
| 48. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE |
| 49. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE |
| 50. | NSS | [8] | NOT SOLD SEPARAT | CONLINK |
| 51. | NSS | [4] | NOT SOLD SEPARAT | CONWASHER |
| 52. | NSS | [4] | NOT SOLD SEPARAT | CONNUT |
| 53. | 2406T1656 | [2] | LEVER | |
| 54. | NSS | [1] | NOT SOLD SEPARAT | CONLEVER ASSY, CONTROL |
| 54-6. | NSS | [2] | NOT SOLD SEPARAT | CONCLAMP |
| 54-7. | NSS | [4] | NOT SOLD SEPARAT | CONCAPSCREW |
| 54-8. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 54-9. | NSS | [2] | NOT SOLD SEPARAT | CONCAPSCREW |
| 54-10. | NSS | [2] | NOT SOLD SEPARAT | CONNUT |
| 54-11. | NSS | [1] | NOT SOLD SEPARAT | CONPIN |
| 54-12. | NSS | [1] | NOT SOLD SEPARAT | CONBRACKET |
| 54-13. | NSS | [2] | NOT SOLD SEPARAT | CONSPACER |
| 54-14. | NSS | [4] | NOT SOLD SEPARAT | CONBEARING, ROLLER |
| 54-15. | NSS | [4] | NOT SOLD SEPARAT | CONSEAL, OIL |
| 54-16. | 6Z1 | [2] | LEVER | KOBBALL, LEVER |
| 54-17. | NSS | [1] | NOT SOLD SEPARAT | CONWASHER |
| 54-18. | NSS | [1] | NOT SOLD SEPARAT | CONCOTTER-PIN |
| 54-26. | NSS | [1] | NOT SOLD SEPARAT | CONPEDAL |
| 54-27. | NSS | [1] | NOT SOLD SEPARAT | CONPEDAL |
| 54-28. | NSS | [1] | NOT SOLD SEPARAT | CONLINK |
| 54-29. | NSS | [1] | NOT SOLD SEPARAT | CONLINK |
| 54-30. | NSS | [2] | NOT SOLD SEPARAT | CONLEVER, CONTROL |
| 55. | 2406U142F2 | [2] | CABLE ASSY, CONTROL, Start Serial: LE4023 | |
| 55-1. | 2406U143F2 | [1] | DEVICE, CONTROL | |
| 55-1A. | 2406U143S1 | [1] | SHAFT | |
| 55-1B. | 2406U143S2 | [5] | CAPSCREW | |
| 55-1C. | 2406U143S3 | [5] | LOCK WASHER | |
| 55-1E. | 2406U143S5 | [1] | CLIP | |
| 55-1F. | 2406U143S6 | [1] | BUSHING | |
| 55-1H. | 2406U143S8 | [1] | BEARING | |
| 55-1I. | 2406U143S9 | [1] | BUSHING | |
| 55-1L. | 2406U143S12 | [1] | LEVER | |
| 55-1M. | 2406U143S13 | [1] | CLIP | |
| 55-1O. | 2406U143S15 | [1] | BALL JOINT | BALL JOINT |
| 55-1P. | 2406U143S16 | [1] | COLLAR | |
| 55-1Q. | 2406U143S17 | [1] | NUT | |
| 55-1R. | 2406U143S18 | [1] | LOCK WASHER | |
| 55-1T. | 2406U143S20 | [1] | BALL & BUSHING | |
| 55-2. | NSS | [2] | NOT SOLD SEPARAT | CONCABLE, CONTROL |
