| . . | 24100X1337F2 | [1] | REMOTE-C0NTROL ASSY, Serial Range: LE3401-LE4161 | |
| . . | 24100X1337F3 | [1] | REMOTE-CONTROL ASSY, Serial Range: LE41R2-LE4636 | |
| . . | 24100X1337F4 | [1] | REMOTE-CONTROL ASSY, Serial Range: LE4637-LE4863 | |
| . . | 24100X1337F5 | [1] | REMOTE-CONTROL ASSY, Start Serial: LE4864 | |
| 1. | R18P0168D43 | [1] | HOSE | KOB, Serial Range: LE3401-LE4636 |
| 2. | ZC15X03300 | [4] | CLIP | KOB |
| 3. | 241RP9767 | [1] | TUBE, Serial Range: LE3401-LE4636 | |
| 4. | ZK33F22012 | [1] | ELBOW | KOB |
| 5. | ZD12P02240 | [1] | O-RING | KOBID 22.10 ± 0.24 x OD 28.4mm |
| 6. | ZH22X06000 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) (PF3/8), Serial Range: LE3401-LE4636 |
| 7. | 2420R537D045 | [1] | HOSE,9.60mm ID x 450mm L | KOB, Serial Range: LE340J-LE3964 Superseded by part number: HX21E06045DX |
| . . | 2420R537D045 | [1] | HOSE,9.60mm ID x 450mm L | KOB, Serial Range: LE3965-LE4636 Superseded by part number: HX21E06045DX |
| 8. | ZH32X06008 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 1/2", O-Ring | KOB90° -- 3/8"PFx1/2"PFx40mm Long (Same as ZD12P02400) |
| 8-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 9. | 2446R151F1 | [1] | ELEMENT | KOBFILTER, LINE Superseded by part number: 2446R183F1 |
| 9-1. | 2446R151S1 | [1] | HEAD | KOB |
| 9-2. | R36P0019 | [1] | HYDRAULIC OIL FILTER | KOB |
| 9-3. | 45Z91D84 | [1] | O-RING | KOBID 56.74 ± 0.25 OD 63.80mm |
| 9-4. | 2446R151S4 | [1] | RING | KOB |
| 9-5. | 2446R151S5 | [1] | CASE | KOB |
| 10. | 2444T1793 | [1] | HYD CONNECTOR | KOB |
| 11. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 15. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 16. | 2418T7100 | [2] | SPACER | SPACER |
| 17. | 2420T3804 | [2] | CAPSCREW | CAPSCREW |
| 18. | ZN16C06005 | [2] | NUT | KOBM06x1.0mm Superseded by part number: ZN18C06005 |
| 19. | ZW16X06000 | [2] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 20. | ZW26X06000 | [11] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 23. | ZH32Z06000 | [1] | ELBOW | KOB |
| 24. | 2416T4212 | [1] | BLOCK | BLOCK |
| 25. | ZS16C08035 | [2] | CAPSCREW | CAPSCREW |
| 26. | ZH22Z04000 | [18] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 27. | 2420R349D14 | [2] | FLEXIBLE HOSE | KOB140mm Long (5-1/2 in) Superseded by part number: HX21E04100DX |
| 28. | 2436U781F1 | [2] | VALVE, PILOT, Serial Range: LE3401-LE4161 | |
| 29. | 2420T4003D1 | [8] | CAPSCREW | CAPSCREW |
| 30. | ZH21K08004 | [4] | HYD CONNECTOR | KOBCONNECTOR |
| 31. | ZX15X08100 | [3] | | |
| 32. | ZH51K08000 | [1] | TEE | KOB |
| 33. | ZH31K08004 | [1] | ELBOW | KOB |
| 34. | ZX15K08022 | [1] | TUBE, N2 | |
| 35. | ZH51K08006 | [1] | TEE | KOB |
| 37. | ZH31K08006 | [1] | ELBOW | KOB |
| 38. | 2420R349D180 | [1] | HOSE,6.35mm ID x 1800mm L | KOB1800mm Long (70-7/8 in) |
| 39. | 2420R349D170 | [2] | FLEXIBLE HOSE | KOB1700mm Long (66-59/64 in) Superseded by part number: HX21E04170DX |
| 40. | 2420R349D230 | [4] | HOSE ASSY. | KOB2300mm Long (90-1/2 in) |
| 41. | ZG52U04000 | [3] | TEE | KOB |
| 42. | ZK23E10004 | [6] | CONNECTOR | |
| 43. | 241RT10473 | [1] | TUBE | |
| 44. | 2418P9768 | [1] | TUBE | |
| 45. | ZK33E10004 | [2] | ELBOW | |
| 46. | 2418P973902 | [1] | TUBE | |
| 47. | 2418T10474 | [1] | TUBE | |
| 48. | ZG22E04000 | [1] | HYD CONNECTOR | KOB |
| 49. | ZH32Z04000 | [2] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| 50. | ZH42Z04000 | [2] | ELBOW | KOB45° -- 1/4"PFx1/4"PTx40mm Long (male both ends) |
| 51. | 2420R349D250 | [1] | HOSE,2500.00 mm | KOB |
| 52. | 2420R349D140 | [1] | HOSE,6.35mm ID x 1400mm L | KOB1/4" PF |
| 53. | ZH21K08006 | [1] | HYD CONNECTOR | KOB |
| 54. | 2432Z29005 | [8] | CLIP | |
| 55. | 2420T3483 | [7] | GROMMET | KOB |
| 56. | 2416P4545 | [2] | STAND, CONTROL, Serial Range: LE3401-LE4161 | STAND, CONTROL, Serial Range: LE3401-LE4161 |
| 57. | 2406T1027 | [2] | LEVER | KOB |
| 58. | 2436U796F1 | [1] | HYDRAULIC VALVE | KOB |
| 59. | 2436U797F1 | [1] | HYDRAULIC VALVE | KOB |
| 60. | 2416T10899 | [1] | BRACKET | |
| 61. | 2422P578 | [1] | F RAME | |
| 62. | 2427P1801 | [1] | TANK | |
| 62-1. | 2444T70D2 | [1] | COUPLING, PIPE | |
| 62-2. | 2418T10389 | [1] | TUBE | |
| 63. | 2422N675 | [1] | PLATE, FLOOR | |
| 63-1. | 241RT12932 | [1] | BRACKET | |
| 63-2. | 2427T834 | [2] | PLATE | |
| 63-3. | ZN11C10008 | [8] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 65. | 2441U507F1 | [1] | PUMP HYDR, Serial Range: LE3401-LE4636 | |
| 66. | 2441U291F2 | [1] | HYDRAULIC PUMP | KOBPUMP, GEAR |
| 67. | ZS13C10025 | [2] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 68. | ZW11K10000 | [2] | WASHER | KOBID 10 x OD 18 x Th 2.0mm |
| 69. | 2436U834F1 | [1] | VALVE RELIEF | VALVE RELIEF |
| 70. | ZS16C06065 | [1] | CAPSCREW | |
| 71. | ZH42Z06000 | [1] | ELBOW | KOB |
| 72. | 2420R537D350 | [1] | HOSE ASSY.,9.60mm ID x 3500mm L | KOB3500mm Long (137-51/64 in), Serial Range: LE3401-LE3964 Superseded by part number: HX21E06350DX |
| 73. | ZX15K08150 | [1] | TUBE | KOB |
| 74. | ZX15K08025 | [1] | KIT | KOB |
| 75. | 2416T10958 | [1] | BRACKET | |
| 76. | ZG52U06000 | [1] | TEE | KOB, Serial Range: LE3401-LE5230 |
| 77. | ZG22E06000 | [1] | HYD CONNECTOR | KOBNIPPLE, Serial Range: LE3401-LE5230 |
| 78. | 2436U811F6 | [2] | VALVE, PILOT, Serial Range: LE4162-LE4863 | VALVE, PILOT, Serial Range: LE4162-LE4863 |
| 79. | 2416P4545D2 | [2] | STAND, CONTROL, Start Serial: LE4162 | |
| 80. | 2414T2053 | [2] | COVER | KOB, Start Serial: LE4162 |
| 81. | 2414T2052 | [2] | COVER, Start Serial: LE4162 | COVER, Start Serial: LE4162 |
| 82. | 2414R230 | [2] | BOOT | KOB, Start Serial: LE4162 |
| 83. | R18P0168D47 | [1] | HOSE | KOB, Start Serial: LE4637 |
| 84. | 2418P9983 | [1] | TUBE, Start Serial: LE4637 | |
| 85. | ZH32X06000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006, Start Serial: LE4637 |
| 85-1. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 86. | 2420R537D057 | [1] | HOSE, Start Serial: LE4637 | |
| 87. | 2436U811F9 | [2] | PILOT VALVE | KOB, Start Serial: LE4864 |
| 88. | ZG22B06004 | [1] | HYD CONNECTOR | KOBBUSHING, Start Serial: LE5231 |
| 89. | ZE82T04000 | [1] | PLUG | KOB1/4" PT, Start Serial: LE5231 |
