| . . | 24100X1354F1 | [1] | CONTROL ASSY | |
| 1. | R18P0168D47 | [1] | HOSE | KOB |
| 2. | ZC15X03300 | [4] | CLIP | KOB |
| 3. | 2418P9983 | [1] | TUBE | |
| 4. | ZK33F22012 | [1] | ELBOW | KOBELBOW |
| 5. | ZD12P02240 | [1] | O-RING | KOBID 22.10 ± 0.24 x OD 28.4mm |
| 6. | ZH32X06003 | [1] | ELBOW, 90° | |
| 6-1. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 7. | 2420R537D045 | [1] | HOSE,9.60mm ID x 450mm L | KOB Superseded by part number: HX21E06045DX |
| 8. | ZH32X06008 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 1/2", O-Ring | KOB90° -- 3/8"PFx1/2"PFx40mm Long (Same as ZD12P02400) |
| 8-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 9. | 2446R151F1 | [1] | ELEMENT | KOBFILTER, LINE Superseded by part number: 2446R183F1 |
| 9-1. | 2446R151S1 | [1] | HEAD | KOB |
| 9-2. | R36P0019 | [1] | HYDRAULIC OIL FILTER | KOB |
| 9-3. | 45Z91D84 | [1] | O-RING | KOBID 56.74 ± 0.25 OD 63.80mm |
| 9-4. | 2446R151S4 | [1] | RING | KOB |
| 9-5. | 2446R151S5 | [1] | CASE | KOB |
| 10. | 2444T1793 | [1] | HYD CONNECTOR | KOBCONNECTOR |
| 11. | ZD12P01800 | [5] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 12. | 2436U834F1 | [1] | VALVE RELIEF | VALVE RELIEF |
| 14. | ZS16C06065 | [1] | CAPSCREW | |
| 15. | ZW26X08000 | [10] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 16. | 2418T7100 | [2] | SPACER | SPACER |
| 17. | 2420T3804 | [2] | CAPSCREW | CAPSCREW |
| 18. | ZN16C06005 | [2] | NUT | KOBM06x1.0mm Superseded by part number: ZN18C06005 |
| 19. | ZW16X06000 | [2] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 20. | ZW26X06000 | [11] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 22. | 2420R537D350 | [1] | HOSE ASSY.,9.60mm ID x 3500mm L | KOB3500mm Long (137-51/64 in) Superseded by part number: HX21E06350DX |
| 23. | ZH32Z06000 | [1] | ELBOW | KOB |
| 24. | 2416T4212 | [1] | BLOCK | BLOCK |
| 25. | ZS16C08035 | [2] | CAPSCREW | CAPSCREW |
| 26. | ZH22Z04000 | [8] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 27. | 2420R349D21 | [2] | HOSE | HOSE |
| 28. | 2436U944F5 | [2] | PILOT VALVE | KOB |
| 29. | ZS23C06020 | [8] | SCREW,Hex Socket Head, M6 x 20mm | KOBM06x1.0x20mm Superseded by part number: ZS28C06020 |
| 30. | ZH21K08004 | [7] | HYD CONNECTOR | KOB |
| 31. | ZX15K08150 | [3] | TUBE | KOB |
| 32. | ZH51K08000 | [2] | TEE | KOB |
| 33. | ZH31K08004 | [1] | ELBOW | KOB |
| 34. | ZX15K08022 | [1] | TUBE, N2 | |
| 35. | ZH51K08006 | [1] | TEE | KOB |
| 36. | ZX15K08033 | [1] | TUBE,NYLON | |
| 37. | 2444Z2086D1 | [1] | TEE | KOB |
| 38. | 2420R349D180 | [1] | HOSE,6.35mm ID x 1800mm L | KOB1800mm Long (70-7/8 in) |
| 39. | 2420R349D170 | [2] | FLEXIBLE HOSE | KOB1700mm Long (66-59/64 in) Superseded by part number: HX21E04170DX |
| 40. | 2420R349D230 | [4] | HOSE ASSY. | KOB |
| 41. | 2652U04000 | [3] | TEE | |
| 42. | ZK23E10004 | [7] | CONNECTOR | |
| 43. | 2418T10473 | [1] | TUBE | |
| 44. | 2418P9768 | [1] | TUBE | |
| 45. | ZK33E10004 | [2] | ELBOW | |
| 46. | 2418P9739D2 | [1] | TUBE | |
| 47. | 2418T10474 | [1] | TUBE | |
| 48. | ZG22E04000 | [1] | HYD CONNECTOR | KOB |
| 49. | ZH32Z04000 | [3] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| 50. | ZH42Z04000 | [12] | ELBOW | KOB45° -- 1/4"PFx1/4"PTx40mm Long (male both ends) |
| 51. | 2420R349D250 | [1] | HOSE,2500.00 mm | KOB |
| 52. | 2420R349D147 | [1] | HOSE | |
| 53. | 2444Z2226 | [2] | CONNECTOR | CONNECTOR |
| 54. | ZW42Z06000 | [3] | ELBOW | |
| 55. | ZX15K08055 | [2] | TUBE NYLON | TUBE NYLON |
| 56. | 24100U322F2 | [1] | SOLENOID VALVE | KOB |
| 57. | ZE82T06000 | [1] | PLUG | KOBPipe, 3/8" PT |
| 58. | 2436U796F1 | [1] | HYDRAULIC VALVE | KOB |
| 59. | 2436U797F1 | [1] | HYDRAULIC VALVE | KOB |
| 60. | 2416T10899 | [1] | BRACKET | |
| 61. | ZG22E06000 | [1] | HYD CONNECTOR | KOB, Serial Range: LE4637-LE5230 |
| 62. | ZG52U06000 | [1] | TEE | KOB, Serial Range: LE4637-LE5230 |
| 63. | ZH21K08006 | [1] | HYD CONNECTOR | KOB |
| 64. | 2416T10958 | [1] | BRACKET | |
| 65. | ZS23C06016 | [4] | SCREW,Hex Socket Head, M6 x 16mm | KOBM06x1.0x16mm Superseded by part number: ZS28C06016 |
| 66. | ZW22K06000 | [4] | LOCK WASHER | KOBID 06 x OD 10 x Th 1.5mm |
| 6S. | 2441U291F2 | [1] | HYDRAULIC PUMP | KOB |
| 69. | 2420R537D057 | [1] | H0SE | |
| 70. | ZH31K08006 | [1] | ELBOW | KOB |
| 71. | ZG22B06004 | [1] | HYD CONNECTOR | KOB, Start Serial: LE5231 |
| 72. | ZE82T04000 | [1] | PLUG | KOB1/4" PT, Start Serial: LE5231 |
