纽荷兰零件查询(AD300) - ARTICULATED DUMP TRUCK (1/01-) (0.550/3[05]) - ENGINE - GEARBOX OIL COOLING SYSTEM - PIPING - RETARDER OPTION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
738 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 8900191133 | [4] | FLANGE | AST |
| 2. | 8900005720 | [2] | SEALING RING | ASTSEALRING |
| 3. | 8900005074 | [8] | BOLT | AST |
| 4. | 8900101820 | [8] | SPRING WASHER | AST |
| 5. | 89500403638 | [2] | HOSE ASSY. | AST |
| 6. | 89500401230 | [2] | ELBOW | AST |
| 7. | 89500401232 | [1] | FLEXIBLE HOSE | AST |
| 8. | 89500401234 | [1] | HYD CONNECTOR | AST |
| 9. | 89500401235 | [1] | HYD CONNECTOR | AST |
| 10. | 8900191101 | [1] | HYD CONNECTOR | AST |
| 11. | 89500401396 | [1] | BRACKET | AST |
| 12. | 8900172961 | [1] | BOLT | ASTM8 x 30 |
| 13. | 8900141697 | [2] | WASHER | AST |
| 14. | 8900016391 | [1] | NUT | ASTM8 |
