纽荷兰零件查询(AD300) - ARTICULATED DUMP TRUCK (1/01-) (1.212/3[06A]) - TRANSMISSION - HOUSING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
311 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 8900128921 | [1] | BOX | AST |
| 2. | 8900126568 | [1] | COVER | AST |
| 3. | 8900130460 | [12] | BOLT | ASTM10X32 Superseded by part number: 8605388 |
| 5. | 8900126571 | [2] | PIN | AST Superseded by part number: 100073A1 |
| 6. | 8900126572 | [1] | DEFLECTOR | AST |
| 7. | 8900126573 | [1] | DEFLECTOR | AST |
| 8. | 8900126574 | [2] | COVER | AST Superseded by part number: E1NN3B167AB |
| 9. | 8900130461 | [5] | BOLT | ASTM8X16 Superseded by part number: 8605389 |
| 10. | 8963100278 | [5] | WASHER | AST Superseded by part number: 86624185 |
| 11. | 8963100392 | [1] | NUT | ASTM8 Superseded by part number: 43362 |
| 12. | 8963100256 | [2] | NUT | ASTM10 Superseded by part number: 100016 |
| 13. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 15. | 8900130462 | [1] | BOLT | ASTM10X55 Superseded by part number: 8605390 |
| 16. | 8900130465 | [8] | SCREW | ASTM10X70 Superseded by part number: 8605391 |
| 17. | 8900130463 | [8] | BOLT | ASTM10X70 Superseded by part number: 8605392 |
| 18. | 8900130464 | [8] | BOLT | ASTM10X40 Superseded by part number: 8605393 |
| 19. | 8900103011 | [2] | PLUG | AST Superseded by part number: 8603319 |
| 20. | 8900111844 | [2] | GASKET | AST Superseded by part number: 8603318 |
| 23. | 8900126580 | [2] | PLATE | AST Superseded by part number: 100081A1 |
| 24. | 8900126581 | [2] | BOLT | ASTM6X25 Superseded by part number: 100082A1 |
| 25. | 8900126582 | [1] | HOSE | AST Superseded by part number: 76081017 |
| 26. | 8900128924 | [1] | BREATHER | AST |
| 27. | 8900126584 | [1] | GASKET | AST Superseded by part number: 8605395 |
| 28. | 8900128922 | [1] | PLUG | AST Superseded by part number: 71448909 |
| 29. | 8963100345 | [1] | SEALING RING | AST |
| 31. | 8900126588 | [4] | PLUG | AST Superseded by part number: 100087A1 |
| 32. | 8900126589 | [4] | GASKET,2.5mm Thk x 38mm ID | AST Superseded by part number: 8603207 |
| 33. | 8900126590 | [1] | ROLL PIN | AST Superseded by part number: 100089A1 |
| 35. | 8900125380 | [1] | PLUG | AST Superseded by part number: 641-3320 |
