纽荷兰零件查询(AD300) - ARTICULATED DUMP TRUCK (1/01-) (2.357/3[01A]) - FRONT SUSPENSION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
925 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 89500402755 | [1] | YOKE | AST |
| 2. | 89500404821 | [1] | BRACKET | AST Superseded by part number: 89500417446, 89500416718, 8916673634, 89500416931 |
| 3. | 89500402765 | [1] | SUPPORT | ASTLH |
| 4. | 89500402763 | [1] | SUPPORT | ASTRH |
| 5. | 89500400974 | [1] | FLANGE | AST |
| 6. | 8998197737 | [2] | LINK CONROD | AST |
| 7. | 89500400943 | [2] | CYLINDER | AST Superseded by part number: 89500409174 |
| 8. | 8960530022 | [4] | BUSHING,40.02mm ID x 47.95mm OD x 82mm L | AST |
| 9. | 8960530023 | [2] | PIN | AST |
| 10. | 8960030021 | [4] | SPACER | AST |
| 11. | 8900194983 | [2] | SHIELD | AST |
| 12. | 8998196140 | [2] | SPACER | AST |
| 13. | 8998197569 | [2] | SHIM | AST |
| 14. | 8960530006 | [2] | PIN,40mm OD x 104mm L | AST |
| 15. | 8960410006 | [4] | BUSHING | AST |
| 16. | 8900194934 | [2] | PIN,50mm OD x 160mm L | AST |
| 17. | 8900194891 | [8] | BUSHING,50mm ID x 67mm OD x 38mm L | AST |
| 18. | 8900045015 | [4] | BUSHING | AST |
| 19. | 8900194939 | [2] | PIN,50mm OD x 225mm L | AST |
| 20. | 8960530027 | [2] | RING | AST |
| 21. | 8960410053 | [1] | SHIM | AST1 mm |
| 21. | 8960410054 | [1] | SHIM | AST2 mm |
| 22. | 8960430396 | [2] | BUSHING,50mm ID x 60mm OD x 45mm L | AST |
| 23. | 8960530026 | [2] | SPACER | AST |
| 24. | 8960530252 | [2] | BUSHING,220mm ID x 300mm OD x 100mm L | AST |
| 25. | 8960460019 | [2] | OIL SEAL | AST |
| 27. | 8900194229 | [2] | BOLT | ASTM12 x 220 |
| 28. | 8900101696 | [4] | NUT | ASTM12 |
| 29. | 8900125740 | [6] | BOLT | ASTM20 x 40 |
| 30. | 8900140552 | [32] | COLLAR | AST |
| 31. | 8900194218 | [1] | PLATE | AST |
| 32. | 8916707734 | [8] | BOLT | ASTM8 x 50 |
| 33. | 89500402770 | [8] | TIGHTENER SHEAVE | AST |
| 34. | 8900119099 | [4] | NUT | ASTM20 x 2.5 |
| 35. | 8916631334 | [2] | BOLT | ASTM12 x 140 |
| 36. | 8900107675 | [6] | BOLT | ASTM16 x 35 |
| 37. | 8900140501 | [6] | COLLAR | AST |
| 38. | 8900015972 | [4] | CIRCLIP | AST |
| 39. | 8900101799 | [8] | SCREW,M10 x 25mm | ASTM10 x 25 |
| 40. | 8900125037 | [16] | BOLT | ASTM10 x 30 |
| 41. | 8900124113 | [16] | WASHER | AST Superseded by part number: 8900040256 |
| 42. | 8900125706 | [3] | ROLL PIN | AST |
| 43. | 8900056673 | [6] | STUD | ASTM20 x 1.5 x 45 |
| 44. | 8900125708 | [4] | STUD | ASTM20 x 90 Superseded by part number: 8916740335 |
| 45. | 8900051937 | [14] | NUT | ASTM20 Superseded by part number: 8900151937 |
| 46. | 8900172054 | [4] | BOLT | ASTM20 x 1.5 x 65 |
| 47. | 8917154831 | [8] | NUT | ASTM8 |
| 48. | 89500405165 | [2] | PLATE | AST Superseded by part number: 89500414650, 8916740335, 8900140501 |
