纽荷兰零件查询(AD300) - ARTICULATED DUMP TRUCK (1/01-) (3.413A[10A]) - DISTRIBUTOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
577 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 89500404277 | [1] | CONTROL VALVE | AST |
| 2. | 8900128537 | [1] | SEAL KIT | AST Superseded by part number: 151703113 |
| 3. | 8900128538 | [1] | VALVE POPPET | AST |
| 4. | 8900128539 | [2] | BOLT | AST |
| 5. | 8900128540 | [2] | LOCK WASHER | AST |
| 6. | 8900128541 | [16] | BOLT | AST Superseded by part number: 3146908R1 |
| 7. | 8900128542 | [16] | LOCK WASHER | AST |
| 8. | 8900128543 | [1] | COVER | AST |
| 9. | 8900128544 | [1] | COVER | AST |
| 10. | 8900128545 | [1] | PLATE | AST |
| 11. | 8900128546 | [1] | PLATE | AST |
| 12. | 8900128547 | [1] | SAFETY VALVE | AST |
| 13. | 8900128548 | [1] | PLUG | AST Superseded by part number: 79104736 |
| 14. | 8900128549 | [2] | HYDRAULIC VALVE | AST |
| 15. | 8900128550 | [1] | PLUG | AST |
| 16. | 8900128551 | [2] | PLUG | AST |
| 17. | 8900128552 | [2] | GUIDE | AST |
| 18. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 19. | 8900128554 | [3] | BREATHER | AST |
| 20. | 8900128555 | [2] | SPRING | AST |
| 21. | 8900128556 | [2] | SPRING | AST |
| 22. | 8900128557 | [1] | SPRING | AST |
| 24. | 8900128559 | [2] | BREATHER | AST |
| 25. | 8900128560 | [1] | PLUG | AST |
| 26. | 8900128561 | [1] | HYDRAULIC VALVE | AST |
| 27. | 8900128562 | [1] | SPRING | AST |
| 28. | 8900128563 | [1] | SPRING | AST |
