神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (04-008) - ALARM, OVER LOAD (FOR EXPORT) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
574 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100W2866F1 | [1] | ALARM/ OVER LOAD | |
| 1. | 2419T3552 | [1] | PIN | |
| 2. | 2419T3549 | [1] | PIN | |
| 3. | 2416T11057 | [1] | BRACKET | |
| 4. | 2416P7290F1 | [1] | BRACKET | |
| 4-4. | 2405T990 | [1] | BUSHING | |
| 5. | 2418N2231 | [1] | PLATE, CAM | |
| 6. | 2416T11055 | [1] | BRACKET | |
| 7. | 2411T1196 | [1] | BOSS | |
| 8. | 2436U820F1 | [1] | SWITCH, PRESSURE | |
| 9. | 2418T10361 | [1] | PIPE | |
| 10. | ZP26D08018 | [2] | PIN, SPRING | |
| 11. | ZP26D06016 | [1] | PIN | KOBSpring |
| 12. | ZS13C24140 | [1] | SCREW | HITM24x3.0x140mm |
| 13. | ZS23C08030 | [3] | SCREW,Hex Socket Head, M8 x 30mm | KOBM08x1.25x30mm Superseded by part number: ZS28C08030 |
| 14. | ZS23C06030 | [2] | SCREW,Hex Socket Head, M6 x 30mm | KOBM06x1.0x30mm |
| 15. | ZN11C12010 | [2] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 16. | ZW22X24000 | [1] | WASHER | KOB |
| 17. | ZW22X12000 | [1] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 18. | ZW22K08000 | [1] | LOCK WASHER | KOBID 08 x OD 13 x Th 2.0mm |
| 19. | 2418T10352 | [1] | PLATE | |
| 20. | ZW11X12000 | [1] | WASHER | KOBID 12 x OD 24 x Th 2.3mm Superseded by part number: ZW16X12000 |
| 21. | 2418P9911 | [1] | TUBE | |
| 22. | 2418P9910 | [1] | TUBE | |
| 23. | ZS11C08025 | [2] | CAPSCREW | |
| 24. | ZN11C08007 | [3] | NUT | KOBM08x1.25mm Superseded by part number: ZN16C08007 |
| 25. | 2420T2277D3 | [1] | U-BOLT | |
| 26. | 2436R620F1 | [1] | VALVE PRESSURE RELIE | KOB |
| 27. | ZF23G12004 | [3] | CONNECTOR | CONNECTOR |
| 28. | ZF23E12004 | [1] | CONNECTOR | |
| 29. | ZF53B12000 | [1] | TEE | KOB |
| 30. | ZW22K06000 | [2] | LOCK WASHER | KOBID 06 x OD 10 x Th 1.5mm |
| 31. | ZF83P12000 | [1] | PLUG | KOBPLUG |
| 32. | ZF93N12000 | [1] | NUT | KOB |
| 33. | ZN16C06005 | [4] | NUT | KOBM06x1.0mm Superseded by part number: ZN18C06005 |
| 34. | ZW22X08000 | [2] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 35. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 36. | ZX58N06140 | [1] | HOSE | |
| 37. | 2421N150 | [1] | BOX/ TOOL | |
| 38. | 2416T12850 | [1] | BOSS | |
| 39. | 2420T4435 | [1] | CAPSCREW | |
| 40. | ZN12C16010 | [1] | NUT | KOB |
| 41. | 2416T10975 | [1] | BRACKET | |
| 42. | 2479Z444 | [1] | BUZZER | |
| 43. | R79P0060F1 | [1] | LAMP | KOB |
| 44. | ZM11C06016 | [1] | BOLT | KOB |
| 45. | 2479Z895 | [1] | HARNESS | |
