| . . | 24100X1213F2 | [1] | POWER PLANT, Serial Range: LE3401-LE4161 | |
| . . | 24100X1213F4 | [1] | POWER-PLANT ASSY, Serial Range: LE4162-LE4636 | |
| . . | 24100X1213F5 | [1] | POWER-PLANT ASSY, Start Serial: LE4637- | |
| 1. | 2451U222F1 | [1] | ENGINE | KOB |
| 2. | 24100N260F1 | [1] | PUMP ASSY, CONNECT, SEE FIG 08-004, Serial Range: LE3401-LE4636 | |
| 3. | 2451U223 | [1] | MUFFLER | KOB |
| 5. | 2416N2374 | [1] | BRACKET | BRACKET |
| 6. | 2418N1868 | [1] | RIGID TUBE | KOB |
| 7. | 2446R150D8 | [1] | AIRCLEANER | AIRCLEANER |
| 7-1. | 2446R150D8S1 | [1] | ELEMENT | ELEMENT |
| 8. | 2432Z162D2 | [2] | BAND | BAND |
| 9. | 2418N1869 | [1] | PIPE | PIPE |
| 10. | 2418P7701 | [1] | PIPE | |
| 11. | 2444T2014D2 | [1] | FLEXIBLE HOSE | KOB |
| 12. | 2444T2014D1 | [1] | FLEXIBLE HOSE | KOB |
| 13. | 2446R153F2 | [1] | INDICATOR | KOB, Serial Range: LE3401-LE4161 |
| 18. | 2420T4162 | [1] | GASKET | KOB Superseded by part number: VI9141450761 |
| 19. | 2420T4163 | [2] | U-BOLT | KOB |
| 20. | 2416U23 | [2] | RUBBER, CUSHION (72), Serial Range: LE3401-LE3916 | |
| 21. | 2416U24 | [2] | RUBBER, CUSHION (73) LE34, Serial Range: 01-LE3916 | |
| 23. | 2432T812F1 | [1] | CLAMP | KOB |
| 25. | ZC15X04000 | [4] | CLIP | KOB |
| 27. | ZC15X01500 | [4] | CLIP | KOB |
| 28. | 2489R148 | [1] | SENDER UNIT | KOB |
| 29. | 2489U123 | [1] | SENDER UNIT | KOB, Serial Range: LE3401-LE4161 |
| 30. | 2416P6393 | [2] | BRACKET | |
| 31. | 2416P6394 | [1] | BRACKET | |
| 33. | ZS16C12030 | [4] | CAPSCREW M12x1.75x30mm | CAPSCREW M12x1.75x30mm |
| 35. | ZS16C12030 | [8] | CAPSCREW M12x1.75x30mm | CAPSCREW M12x1.75x30mm |
| 36. | ZS16C08016 | [4] | SCREW | KOBM08x1.25x16mm Superseded by part number: ZS18C08016 |
| 39. | ZN16C10008 | [12] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 40. | ZN16C08007 | [4] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08007 |
| 41. | ZW26X16000 | [2] | LOCK WASHER | KOBID 16 x OD 28 x Th 4.0mm |
| 42. | ZW26X12000 | [8] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 43. | ZW26X10000 | [25] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 44. | ZW22X08000 | [6] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 45. | ZW16X10000 | [8] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 47. | 2452022F1 | [1] | RADIATOR ASSY, SEE FIG 08-011, Serial Range: LE3401-LE4636 | |
| 49. | 2444T2033 | [1] | FLEXIBLE HOSE | KOB |
| 50. | 2444T2034 | [4] | FLEXIBLE HOSE | KOB |
| 51. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 52. | ZS18C10025 | [12] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 54. | ZN16F16013 | [2] | NUT | |
| 55. | ZN16F12010 | [4] | NUT LE3 4, Serial Range: 01-LE3916 | NUT LE3 4, Serial Range: 01-LE3916 |
| 56. | ZN12F10008 | [3] | NUT | KOB Superseded by part number: 77276130, ZN18F10008 |
| 57. | Z427T830 | [2] | STAY | |
| 58. | NSS | [2] | NOT SOLD SEPARAT | CONLE34, Serial Range: 01-LE4851 |
| 59. | 2427T829 | [1] | EXHAUST SYSTEM PIPE | KOB |
| 60. | 2432216300 | [6] | CLAMP, HOSE | |
| 61. | 2444Z1293D8 | [1] | LUBE NIPPLE | KOB1/4"PTx43mm Long Superseded by part number: R44T0022 |
| 62. | 2420Z795D3 | [1] | HOSE | KOB, Serial Range: LE3401-LE3706~ Superseded by part number: HX11Y07100DX |
| . . | 2420Z795D5 | [1] | HOSE | KOB, Start Serial: LE3707~ Superseded by part number: HX11Y07100DX |
| 63. | ZC15X01300 | [1] | CLIP | KOB |
| 64. | ZS13C10025 | [1] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 65. | 2418T10285 | [1] | PIPE | |
| 66. | ZS11C08035 | [1] | CAPSCREW | |
| 67. | 2432T1738 | [1] | CLAMP | KOB |
| 71. | 2414Z199D25 | [4] | PROTECTIVE SLEEVE | KOBHOSE Superseded by part number: 2414Z199D025 |
| 72. | 2416U23D2 | [2] | RUBBER SLEEVE | KOB, Start Serial: LE3917- |
| 73. | 2416R216 | [2] | RUBBER | KOB, Start Serial: LE3917- Superseded by part number: VI5532150300 |
| 74. | 2420Z993 | [2] | NUT | HIT, Start Serial: LE3917- |
| 75. | 2479R686F1 | [1] | INDICATOR ASSY (83), Serial Range: LE4162-LE4797 | INDICATOR ASSY (83), Serial Range: LE4162-LE4797 |
| 76. | 2489U234 | [1] | THERMOSTAT | KOBPRESSURE, Start Serial: LE4162- Superseded by part number: VI5824100122 |
| 77. | 24100N2260F2 | [1] | PUMP ASSY PUMP ASSY, CONNECT, SEE FIG 08-004, Start Serial: LE4637- | PUMP ASSY PUMP ASSY, CONNECT, SEE FIG 08-004, Start Serial: LE4637- |
| 78. | 2452U221F2 | [1] | RADIATOR RADIATOR ASSY, SEE FIG 08-007, Start Serial: LE4637- | RADIATOR RADIATOR ASSY, SEE FIG 08-007, Start Serial: LE4637- |
| 79. | 24100U333F1 | [1] | TANK | KOBASSY, Start Serial: LE4637- |
| 79-1. | 24100U333S1 | [1] | TANK | TANK |
| 79-2. | 24100U333S2 | [1] | BRACKET | |
| 80. | ZW16X06000 | [1] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm, Start Serial: LE4637- Superseded by part number: 86588450 |
| 81. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm, Start Serial: LE4637- |
| 82. | ZS18C06012 | [2] | SCREW,Hex, M6 x 12mm | KOBM06x1.0x12mm, Start Serial: LE4637- |
| 83. | 2479R686F2 | [1] | INDICATOR, Start Serial: LE4798- | INDICATOR, Start Serial: LE4798- |
| 84. | 4018Z1D10 | [2] | FLEXIBLE HOSE | KOB, Start Serial: LE4852- |
