| . . | 24100X1338F1 | [1] | POWER-PLANT, Serial Range: LE3401--LE4161 | |
| . . | 24100X1338F2 | [1] | POWER-PLANT ASSY, Serial Range: LE4162--LE4636 | |
| . . | 24100X1338F3 | [1] | POWER-PLANT ASSY, Start Serial: LE4637- | |
| 1. | 2451U222F2 | [1] | ENGINE | |
| 2. | 24100N2260F1 | [1] | PUMP ASSY, CONNECT, SEE FIG 08-001, Serial Range: LE3401-LE4636 | |
| 3. | 2427U295D2 | [1] | MUFFLER | MUFFLER |
| 4. | 2416P7170 | [2] | BRACKET | |
| 5. | 2427P1793 | [1] | PIPE, EXHAUST,(67), Serial Range: LE3401-LE5230 | |
| 6. | 24468150D2 | [1] | AIR CLEANER | |
| 6-1. | 2446R150D2S1 | [1] | ELEMENT | |
| 7. | 2432Z162D3 | [2] | BAND ASSY | BAND ASSY |
| 8. | 2416P7178 | [1] | BRACKET | |
| 9. | 2444Z2104D1 | [1] | HOSE | |
| 10. | 2418U2203 | [1] | PIPE | |
| 11. | 2446P153F2 | [1] | INDICATOR, Serial Range: LE3401-LE4161 | |
| 12. | 2444T2014D1 | [1] | FLEXIBLE HOSE | KOB |
| 13. | 2418P7701 | [1] | PIPE | |
| 14. | 2452U221F1 | [1] | RADIATOR ASSY, SEE FIG 08-006, Serial Range: LE3401-LE4636 | |
| 15. | 2427T830 | [2] | STAY | |
| 16. | 2444T2033 | [1] | FLEXIBLE HOSE | KOB |
| 17. | 2444T2034 | [1] | FLEXIBLE HOSE | KOB |
| 18. | 2489R8148 | [1] | SENDING UNIT | |
| 19. | 2489U123 | [1] | SENDER UNIT | KOB |
| 20. | 2416P6393 | [2] | BRACKET, Serial Range: LE3401-LE4161 | |
| 23. | R18P0136D4 | [2] | HOSE | KOB, Serial Range: LE3401--LE4851 |
| 24. | 2414Z199D25 | [4] | PROTECTIVE SLEEVE | KOB Superseded by part number: 2414Z199D025 |
| 25. | 2420Z962D1 | [1] | TUBE, VINYL | |
| 26. | 2432Z163D2 | [6] | CLAMP, HOSE, Serial Range: LE3401-LE3867 | CLAMP, HOSE, Serial Range: LE3401-LE3867 |
| . . | 2432Z163D2 | [4] | CLAMP, HOSE, Start Serial: LE3868- | CLAMP, HOSE, Start Serial: LE3868- |
| 27. | ZC15X04000 | [4] | CLIP | KOB |
| 28. | ZC15X01500 | [4] | CLIP | KOB |
| 29. | 2432Z428D3 | [1] | CLIP | |
| 30. | 2420T4367 | [2] | U-BOLT | KOB |
| 31. | ZS18C10018 | [4] | SCREW,Hex, M10 x 18mm | KOBM10x1.50x18mm |
| 32. | ZS16C10020 | [10] | CAPSCREW M10x1.50x20mm | CAPSCREW M10x1.50x20mm |
| 33. | ZS16C08016 | [8] | SCREW | KOBM08x1.25x16mm Superseded by part number: ZS18C08016 |
| 34. | ZS13C10025 | [4] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 35. | ZS16C12030 | [4] | CAPSCREW M12x1.75x30mm | CAPSCREW M12x1.75x30mm |
| 34. | ZS18C10025 | [12] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 37. | ZS18C08020 | [1] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 38. | ZN16C08007 | [16] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08007 |
| 39. | ZN16F16013 | [2] | NUT | |
| 40. | ZN16F12010 | [4] | NUT, Serial Range: LE3401-LE3916 | NUT, Serial Range: LE3401-LE3916 |
| . . | ZN16F12010 | [2] | NUT, Start Serial: LE3917- | NUT, Start Serial: LE3917- |
| 41. | ZN16C10008 | [4] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 42. | ZW16X10000 | [8] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 43. | ZW26X10000 | [32] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 44. | ZW26X08000 | [10] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 45. | ZW26X12000 | [8] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 46. | ZW26X16000 | [2] | LOCK WASHER | KOBID 16 x OD 28 x Th 4.0mm |
| 47. | 24270297 | [1] | SILENCER | |
| 48. | 2432Z162D4 | [2] | BAND | KOB |
| 49. | 2444Z2229D1 | [1] | HOSE | |
| 50. | 2414P2918 | [1] | COVER | |
| 51. | 2432T812F1 | [1] | CLAMP | KOB |
| 52. | 2412F10008 | [2] | NUT | |
| 55. | 241602300 | [2] | RUBBER, CUSHION | |
| 54. | 2416R216 | [7] | RUBBER | KOB Superseded by part number: VI5532150300 |
| 55. | 2432Z163D3 | [2] | CLAMP | KOB, Start Serial: LE3868- |
| 56. | 2420Z993 | [2] | NUT | HIT, Start Serial: LE3917- |
| 57. | 2479R686F1 | [1] | INDICATOR LE416 2 to LE47 97 | INDICATOR LE416 2 to LE47 97 |
| 58. | 2489U234 | [1] | THERMOSTAT | KOB, Start Serial: LE4162- Superseded by part number: VI5824100122 |
| 59. | 24100N2260F2 | [1] | PUMP ASSY PUMP ASSY, CONNECT, SEE FIG 08-004, Start Serial: LE4637- | PUMP ASSY PUMP ASSY, CONNECT, SEE FIG 08-004, Start Serial: LE4637- |
| 60. | 2452U221F2 | [1] | RADIATOR RADIATOR ASSY, SEE FIG 08-007, Start Serial: LE4637- | RADIATOR RADIATOR ASSY, SEE FIG 08-007, Start Serial: LE4637- |
| 61. | 24100U333F1 | [1] | TANK | KOBTANK ASSY, Start Serial: LE4637- |
| 61-1. | 24100U333S1 | [1] | TANK | TANK |
| 61-2. | 24100U333S2 | [1] | BRACKET | |
| 62. | ZS18C06012 | [2] | SCREW,Hex, M6 x 12mm | KOBM06x1.0x12mm, Start Serial: LE4637- |
| 63. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm, Start Serial: LE4637- |
| 64. | ZW16X06000 | [1] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm, Start Serial: LE4637- Superseded by part number: 86588450 |
| 65. | 2479R686F2 | [1] | INDICATOR, Start Serial: LE4798- | INDICATOR, Start Serial: LE4798- |
| 66. | 4018Z1D10 | [2] | FLEXIBLE HOSE | KOB, Start Serial: LE4852~ |
| 67. | 2427P1831 | [1] | PIPE, EXHAUST, Start Serial: LE5231-- | PIPE, EXHAUST, Start Serial: LE5231-- |
